凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (61.904.AB[07]) - TANK PRESSURE, 350 BUSHEL 6 RUN, 350 BUSHEL 8 RUN SINGLE SHOOT, TOW BEHIND Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
282 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47615447
|
[2] |
PLATE
|
SAS
Mounting
|
| 2. |
VF-503
|
[2] |
CLAMP
|
FLX
Distribution Tube Clamp
|
| 3. |
47614338
|
[1] |
TUBE
|
SAS
Pressurization
|
| 4. |
47456417
|
[2] |
TUBE
|
SAS
Product Delivery, Short
|
| 5. |
120073
|
[2] |
BOLT,Hex, M10 x 86.58mm, Cl 8.8
|
NH
Superseded by part number: 129796A1
|
| 6. |
86619802
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
PA
Superseded by part number: 87547587
|
| 7. |
4731
|
[1] |
CAP
|
FLX
|
| 8. |
86050197
|
[3] |
HOSE CLAMP,58.6mm - 82.5mm, Worm Gear
|
FOR
|
| 9. |
47679558
|
[1] |
HOSE, BULK
|
SAS
Cut to Length of 3400mm
|
| 9. |
47688565
|
[1] |
HOSE, BULK
|
SAS
Bulk 50 Foot Cut to Length of 2200mm
|
| 10. |
8060
|
[2] |
CAP
|
FLX
|
| 11. |
513309
|
[6] |
HOSE CLAMP,1-1/16" - 2", Worm
|
NH
|
| 12. |
87557086
|
[8] |
CABLE TIE
|
SAS
|
