神钢零件查询(MD200BLC) - EXCAVATOR ASN YQU0001 (1/80-12/06) (08-007) - BUZZER ASSY, BACK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
772 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4097F2 | [1] | BUZZER ASSY, BACK | |
| 1. | 2416P8798 | [1] | BRACKET | KOB |
| 4. | 2447R102 | [1] | BUZZER | KOBBACK |
| 5. | ZS18C10050 | [2] | SCREW,Hex, M10 x 50mm | KOBM10x1.50x50mm |
| 6. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 7. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 8. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 9. | ZS18C06020 | [2] | SCREW,Hex, M6 x 20mm | KOBM06x1.0x20mm |
| 10. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 11. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 15. | 2479Z1452 | [2] | SWITCH | KOB |
| 16. | 2418T16770 | [1] | PLATE | KOB |
| 17. | NSS | [1] | NOT SOLD SEPARAT | CONPOWER-PLANT, SEE FIGURE 05-001 |
