凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (61.904.AB[12]) - METERING SEED TUBE MOUNT, 350 BUSHEL 6 RUN, 555 BUSHEL 7 RUN, 350, 555 BUSHEL 8 RUN SINGLE SHOOT, TOW BEHIND Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
314 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47602947
|
[1] |
BRACKET
|
SAS
Tube, 10 Run
|
| 2. |
47548964
|
[1] |
TUBE
|
SAS
Mount, 10 Run
|
| 3. |
47602953
|
[2] |
PLATE
|
SAS
Tube Mount
|
| 4. |
87033737
|
[18] |
WASHER,9mm ID x 28mm OD x 3mm Thk
|
BRR
|
| 5. |
300807
|
[9] |
BOLT,Hex, M8 x 140, 8.8
|
ZED
|
| 6. |
68841
|
[9] |
NUT,M8 x 1.25, Cl 8
|
BER
Superseded by part number: 16104414
|
| 7. |
47534143
|
[2] |
U-BOLT,M16 x 2, Square, 180mm W x 175mm L
|
SAS
|
| 8. |
140020
|
[4] |
WASHER,17.5mm ID x 30mm OD x 3mm Thk
|
NH
|
| 9. |
146988
|
[4] |
LOCK NUT,M16 x 2, Cl 8
|
BER
Superseded by part number: 86000441
|
| 10. |
43140
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 11. |
100037
|
[4] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
86625253
|
[4] |
WASHER,11mm ID x 24mm OD x 2mm Thk
|
FAR
|
