纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (194-17[1]) - DOOR ASSY, CAB (GRAYISH BLACK) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
164 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB51C00004F1%KL | [1] | DOOR | KOBDoor Assy, Cab (grayish Black) |
| 1. | YB51C01021P1 | [1] | Panel Assy | |
| 2. | YB02C01066F1 | [1] | GLASS | KOBSash Assy |
| 2-1. | YB02C01067P1 | [1] | FRAME | KOBAssy |
| 2-2. | YB02C01070P1 | [1] | GLASS | KOB |
| 2-3. | YB02C01069P1 | [1] | GLASS | KOB |
| 2-4. | YB02C01068P1 | [1] | SEAL | KOB |
| 2-5. | YN02C02034S005 | [1] | LOCK | KOBAssy |
| 2-6. | YN02C02034S006 | [1] | SEAL | KOB |
| 2-7. | YN02C02034S007 | [1] | SEAL | KOB |
| 2-8. | YN02C02034S008 | [1] | STOP | KOBStopper |
| 2-9. | YN02C02034S009 | [2] | STOP | KOBStopper |
| 3. | YB51C01001P1 | [1] | GLASS | KOB |
| 4. | YB51C01018F1 | [1] | LOCK | KOBAssy |
| 5. | YB51C01019F1 | [1] | HANDLE | KOBAssy |
| 6. | YB51C01020F1 | [1] | HANDLE | KOBAssy |
| 7. | YB51C01005P1 | [1] | GRIP | KOB |
| 8. | YN51C01043P1 | [1] | HOOK | KOB |
| 9. | YB51C01009P1 | [1] | CLIP | KOB |
| 10. | YB51C01004P1 | [1] | SEAL | KOB Superseded by part number: YN51C01180P1 |
| 11. | YB51C01002P1 | [1] | COVER | KOB |
| 12. | YB51C01003P1 | [1] | COVER | KOB |
| 13. | YT51C01039P1 | [1] | GROMMET | KOB |
| 14. | YN51C01046P1 | [1] | HANDLE | KOB |
| 15. | YT02C01295D3 | [1] | RUBBER BAND | KOB |
| 16. | YT02C01295D4 | [1] | RUBBER BAND | KOB |
| 17. | YB51C01016P1 | [1] | GASKET | KOBTrim |
| 18. | YB51C01017P1 | [1] | RUBBER BAND | KOB |
| 19. | YN51C01030P1 | [2] | RUBBER | KOB Superseded by part number: 2418R604 |
| 20. | YN51C01031P1 | [2] | RUBBER SLEEVE | KOB |
| 21. | YT02C01567D4 | [2] | PLATE | KOB(grayish Black) |
| 22. | YT02C01514D5 | [1] | SEAL | KOB Superseded by part number: YR02C01511D2 |
| 23. | YN02C01635P1 | [2] | HINGE | KOB |
| 24. | YT02C01230P1 | [3] | WASHER,6.4mm ID x 12mm OD x 0.5mm Thk | KOB |
| 25. | YT02C01233P1 | [2] | CAP | KOB |
| 26. | YT51C01065D1 | [2] | PLATE | KOB |
| 27. | YT51C01068P1 | [2] | WASHER | KOB |
| 28. | ZM27C10025 | [2] | BOLT | KOBSems |
| 29. | ZM46C06016 | [5] | SCREW | KOBSems-bolt |
| 30. | ZM66C06016 | [5] | BOLT | KOBSems |
| 31. | ZN18C08007 | [2] | NUT | KOB |
| 32. | ZS13C10025 | [6] | CAPSCREW | KOBSCREW Cap Superseded by part number: ZS18C10025 |
| 33. | ZS41C04008 | [2] | CAPSCREW,M4 x 8mm | KOBSCREW Machine |
| 34. | ZS41C06016 | [3] | SCREW,M6 x 16mm | KOBMachine |
| 35. | ZW11X10000 | [6] | WASHER | KOB Superseded by part number: ZW16X10000 |
| 36. | YR09T00003P1 | [1] | PAINT | KOB |
| 37. | YR09T00002P1 | [1] | PAINT | KOB Superseded by part number: YN09T00009P1 |
| 38. | YR01T01005P1 | [1] | ADHESIVE | KOB Superseded by part number: YN01T01067P1 |
| 39. | ZW26X08000 | [2] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| 40. | YT02C01261D4 | [2] | PLATE | KOBPlate (neutral Gray 971) |
| 41. | YN51C01053P1 | [2] | RUBBER | KOB |
