凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (61.904.AD[01]) - FRAME, ROLLER CARTRIDGE, FULL WIDTH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
431 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47795910
|
[1] |
ROLLER
|
SAS
Full Coarse Incl 4,6, Black
|
| 2. |
47357741
|
[1] |
ROLLER
|
SAS
Meter, incl 8
|
| 3. |
47357749
|
[1] |
KNOB
|
SAS
Cartridge Locking
|
| 4. |
47668782
|
[2] |
O-RING
|
SAS
Roller Cartridge
|
| 5. |
86511
|
[2] |
O-RING,0.07" Thk x 1.364" ID, -28, Cl 5, 75 Duro
|
WIN
|
| 6. |
47779533
|
[1] |
CLIP
|
SAS
Extra Fine
|
| 7. |
47788127
|
[1] |
SUPPORT
|
SAS
Cartridge Brace
|
| 8. |
47357750
|
[1] |
BEARING ASSY
|
SAS
|
