纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (244-17[1]) - GUARD INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
193 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF21C00008F1 | [1] | Guard Instal | |
| 1. | LF21C01154F1 | [1] | COVER ASSY | KOBCover Assy |
| 1-1. | LF21C01155P1 | [1] | TOOL BOX | KOBBox |
| 1-2. | LF21C01090P1 | [1] | COVER | KOB Superseded by part number: LF21C01090P2 |
| 1-2C. | LF21C01112F1 | [1] | HINGE | KOBAssy |
| 1-3. | PM21C01268F1 | [1] | LOCK | KOBAssy |
| 1-3A. | YR22C01025P2 | [1] | LOCK | KOB |
| 1-3B. | PM21C01269P1 | [1] | PLATE | KOB |
| 1-4. | YN21C02821P1 | [1] | STAY | KOB |
| 1-5. | ZW16P06000 | [1] | WASHER | KOB |
| 1-6. | 2419R9D1 | [1] | COTTER PIN | KOBSnap |
| 1-7. | ZM73C12020 | [2] | BOLT,M12x20mm - Course Thread | KOBSems |
| 1-8. | YJ21C01103D9 | [1] | WEATHERSTRIP | KOB |
| 1-9. | PM22C01013DL | [1] | WEATHERSTRIP | KOB |
| 1-10. | YJ21C01103D7 | [1] | WEATHERSTRIP | KOB |
| 1-11. | YR21C01168DH | [1] | WEATHERSEAL STRIP | KOBStrip, Weather |
| 2. | LF21C01087F1 | [1] | COVER ASSY | KOB |
| 2-1. | LF21C01136P1 | [1] | Cover | |
| 2-2. | LS21C01093D4 | [1] | TRIM | KOB |
| 3. | LF21C01125F1 | [1] | COVER ASSY | KOB |
| 3-1. | LF21C01126P1 | [1] | Cover | |
| 3-2. | PH21C01136DB | [1] | WEATHERSTRIP | KOB |
| 3-3. | 2427P1836D5 | [1] | EXTRUSION | KOBStrip, Weather |
| 3-4. | YR21C01168D1 | [1] | WEATHERSTRIP | KOB |
| 3-5. | YR21C01168DF | [1] | WEATHERSTRIP | KOB |
| 3-6. | YT21C01164D5 | [1] | WEATHERSTRIP | KOB |
| 4. | YT21C01860F1 | [1] | COVER ASSY | KOB |
| 4-1. | YT21C01861P1 | [1] | COVER | KOBCover |
| 4-2. | YT21C01878P1 | [1] | INSULATION | KOBInsulation |
| 5. | ZM73C12025 | [16] | BOLT,M12x25mm - Course Thread | KOBSems |
| 6. | ZM73C12040 | [1] | BOLT,M12x40mm - Course Thread | KOBSems |
