凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (77.100.AB[05]) - 435, 460, 580 BUSHEL, REAR HYDRAULIC AUGER SADDLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
657 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47505770
|
[1] |
SUPPORT
|
SAS
Auger Superseded by part number: 47996943
|
| 2. |
47505776
|
[1] |
SUPPORT
|
SAS
Auger Saddle, Incl 7 - 8
|
| 3. |
1313
|
[2] |
WASHER,1-1/2" ID x 2-1/4" OD x 10 Ga Thk
|
FLX
Superseded by part number: 81900328
|
| 4. |
86585176
|
[1] |
LUBE NIPPLE,90 Degree, 1/4" NPT x .75" lg
|
GI
Superseded by part number: 87415
|
| 5. |
80714
|
[1] |
LUBE NIPPLE,1/4"-28 NPT x .54" lg
|
PA
Superseded by part number: 87414
|
| 6. |
381928
|
[2] |
ROLL PIN,10mm OD x 50mm L, Slotted
|
ZED
|
| 7. |
9720
|
[1] |
WEAR STRIP
|
FLX
Poly, Rear Saddle Superseded by part number: GL-656A
|
| 8. |
8670
|
[4] |
RIVET,Pop, 3/16" OD x 3/4" L
|
FLX
|
| 9. |
43168
|
[2] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
| 10. |
146988
|
[2] |
LOCK NUT,M16 x 2, Cl 8
|
BER
Superseded by part number: 86000441
|
