| 1. |
84583850
|
[1] |
HYDRAULIC VALVE
|
SAS
Rotary Deluxe Auger
|
| 2. |
84589126
|
[1] |
CONTROL
|
SAS
Auger Valve
|
| 3. |
84589123
|
[1] |
ROD
|
SAS
Auger Valve
|
| 4. |
43130
|
[2] |
BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8
|
NH
|
| 5. |
86629542
|
[2] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 6. |
23781
|
[3] |
GRIP
|
FLX
Handle Superseded by part number: 51200111, 51200111, NLS
|
| 7. |
86983984
|
[2] |
CLAMP
|
SAS
For 2 Hoses
|
| 8. |
120069
|
[2] |
BOLT,M10 x 1.5 x 56.58mm OAL, Cl 8.8
|
NH
|
| 9. |
100037
|
[6] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
47818619
|
[1] |
CHUTE
|
SAS
10" Auger Tube, Incl 11 - 16
|
| 11. |
GD-500.80
|
[1] |
DECAL
|
FLX
Danger, Auger Flighting
|
| 12. |
GD-500.06
|
[1] |
DECAL
|
FLX
Attention, Auger
|
| 13. |
GD-700.43
|
[1] |
Attention When Operating Auger
|
|
| 14. |
22903
|
[2] |
DECAL
|
FLX
Retroreflective, Amber
|
| 15. |
87503917
|
[2] |
DECAL
|
SAS
Auger Direction Bottom
|
| 16. |
419481A1
|
[1] |
DECAL
|
CAS
Danger, Crush
|
| 17. |
218-5065
|
[2] |
HYD CONNECTOR,1-1/16" - 12 Male JIC x 7/8" - 14 Male ORB
|
CAS
Superseded by part number: 72187020, 144124
|
| 18. |
218-5231
|
[3] |
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw
|
CAS
Superseded by part number: 72186121, 219603
|
| 19. |
6248
|
[1] |
LOCK PIN,5/16" x 1 1/2", Slotted
|
FLX
Superseded by part number: 438-12024
|
| 20. |
8559
|
[1] |
PIN,5/16" x 3"
|
FLX
|
| 21. |
88434
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
NH
|
| 22. |
80664
|
[2] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 23. |
47857782
|
[1] |
MOTOR-PUMP
|
SAS
Hydraulic Motor
|
| 24. |
47407473
|
[1] |
HOSE
|
SAS
Auger Discharge
|
| 25. |
84384047
|
[1] |
AUGER FLIGHT
|
SAS
10"
|
| 26. |
86505259
|
[1] |
BOLT,Hex, M12 x 1.75 x 70mm, Cl 10.9
|
NH
|
| 27. |
87533547
|
[1] |
NUT,Prev Torque, M12, 1.75mm Pitch, Cl 10
|
WIC
|
| 28. |
9628065
|
[4] |
SCREW,Hex, M12 x 1.75 x 45mm, Cl 8.8
|
NH
|
| 29. |
100038
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 30. |
GL-657
|
[2] |
RETAINER
|
FLX
Auger Tube
|
| 31. |
9706704
|
[4] |
BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8
|
NH
|
| 32. |
84300017
|
[1] |
ADHESIVE STRIP
|
SAS
Anti-Slip
|
| 33. |
214-14136
|
[2] |
HOSE CLAMP,#136, 8.12" - 9", Type F Worm
|
CAS
|
| 34. |
84424482
|
[1] |
CONTROL
|
SAS
Auger Valve
|
| 35. |
47849180
|
[1] |
SEAL
|
SAS
Used on 23
|
