凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (77.100.AC[02]) - TANK LID MIDDLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
696 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47647527
|
[1] |
STIFFENER
|
SAS
Tank Hatch
|
| 2. |
47649237
|
[2] |
LOCKING TAB
|
SAS
Black
|
| 3. |
47610234
|
[2] |
STIFFENER
|
SAS
Hatch Black
|
| 4. |
86977775
|
[14] |
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
|
ZED
|
| 5. |
100037
|
[16] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 6. |
47598842
|
[14] |
WASHER
|
SAS
|
| 7. |
47487155
|
[2] |
SEAL
|
SAS
Lid Flange
|
| 8. |
1254302C1
|
[2] |
BUSHING,13.5mm ID x 22.2mm OD x 16.7mm L
|
IH
|
| 9. |
86511324
|
[6] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 10. |
335890
|
[2] |
CARRIAGE BOLT,Sq Nk, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
NH
|
| 11. |
9706702
|
[2] |
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
|
NH
|
| 12. |
100038
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 13. |
43140
|
[2] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 14. |
47740942
|
[1] |
Hatch Entry
|
|
| 15. |
47676300
|
[1] |
LID
|
SAS
Hatch Black Incl 23
|
| 16. |
47647192
|
[1] |
SHAFT
|
SAS
Latch Lid
|
| 17. |
47647196
|
[1] |
HANDLE
|
SAS
Latch Lid Black
|
| 18. |
47647204
|
[1] |
TUBE
|
SAS
Latch Bar Black
|
| 19. |
43118
|
[2] |
BOLT,Hex, M6 x 1.0 x 40mm, Cl 8.8
|
NH
Superseded by part number: 120102
|
| 20. |
47649242
|
[2] |
SEAL
|
SAS
Tank Lid
|
| 21. |
47649243
|
[2] |
SEAL
|
SAS
Tank Lid
|
| 22. |
86619800
|
[2] |
FLANGE NUT,M6 x 1, Cl 8
|
RAC
|
| 23. |
47681081
|
[1] |
DECAL
|
SAS
Caution Lid Pressure
|
