神钢零件查询(MD200BLC) - EXCAVATOR BTW YQ0101 - YQ0564 (1/80-12/06) (11-010) - VALVE ASSY, PRESSURE CONTROL- 2436U1170 F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1008 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1170F1 | [1] | CONTROL VALVE | KOBPRESS CONTROL, CONSISTS OF THE FOLLOWING PARTS |
| 01. | 2436U1170S01 | [1] | CASING | |
| 02. | 2436U1170S02 | [1] | SLEEVE | |
| 03. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 04. | 2436U1170S04 | [1] | PISTON | |
| 05. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING |
| 06. | 2436U1170S06 | [1] | SCREW SET | SCREW SET |
| 07. | 2436U1170S07 | [1] | SPRING | KOB |
| 08. | 2436U1170S08 | [1] | O-RING | O-RING |
| 09. | ZD12P01200 | [1] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 12. | 2436U1170S12 | [1] | SOLENOID VALVE | KOB |
| 13. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE |
| 14. | 2436U1170S14 | [4] | PIN | KOBPIN |
| 15. | 2441U474S490 | [2] | PLUG | KOB |
| 16. | 2436U1170S16 | [1] | SPRING | KOBSEAT |
| 17. | ZD12P00500 | [1] | O-RING | KOB |
| 18. | 2436U1170S18 | [1] | CAPSCREW | CAPSCREW |
| 19. | 2436U1170S19 | [4] | CAPSCREW | |
| 20. | 2436U1170S20 | [1] | O-RING | KOB |
| 21. | ZD12P01600 | [1] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
