神钢零件查询(MD200BLC) - EXCAVATOR BTW YQ0101 - YQ0564 (1/80-12/06) (11-013) - VALVE ASSY, REDUCTION- 2436U1283 F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
333 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1283F1 | [1] | VALVE PRESSURE RELIE | KOBASSY, REDUCTION, CONSISTS OF THE FOLLOWING PARTS |
| 521. | 2436U1283S521 | [1] | CASING | |
| 531. | 2436U1283S531 | [1] | SPOOL | KOB |
| 532. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER |
| 533. | NSS | [1] | NOT SOLD SEPARAT | CONFILTER |
| 534. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING |
| 535. | NSS | [1] | NOT SOLD SEPARAT | CONSPACER |
| 536. | NSS | [1] | NOT SOLD SEPARAT | CONORIFICE |
| 541. | 2436U1283S541 | [1] | SPRING | KOB |
| 542. | 2436U1283S542 | [1] | SPRING | KOB |
| 551. | 2436U1283S551 | [3] | SCREW | KOB |
| 552. | 2441U474S490 | [1] | PLUG | KOB |
| 553. | 2441U729S511 | [1] | BALL | KOB |
| 581. | ZD12P01200 | [2] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 582. | ZD12P00600 | [1] | O-RING | KOBID 05.80 ± 0.15 x OD 09mm |
| . . | 2436U1283R100 | [1] | PLUNGER | KOBCONSISTS OF REF 532 - 536 |
