| . . | 2437U182F1 | [1] | HYDRAULIC PUMP | KOBCONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2437U182F1US1 |
| . . | 2437U182F2 | [1] | PUM ASSY, CONSISTS OF THE FOLLOWING PARTS | |
| 111. | 2437U182S111 | [1] | SHAFT | KOB(F) |
| 113. | 2437U182S113 | [1] | SHAFT | KOB(R) |
| 114. | 2441U436S114 | [1] | COUPLING | KOB |
| 115. | 2441U436S115 | [1] | COUPLING | KOB |
| 123. | 2441U436S123 | [2] | BEARING | KOB Superseded by part number: LC10V00002S123 |
| 124. | 2441U436S124 | [2] | NEEDLE BEARING | KOBBEARING |
| 127. | 2441U436S127 | [2] | SPACER | KOB |
| 141. | NSS | [2] | NOT SOLD SEPARAT | CONCYLINDER |
| 151. | NSS | [18] | NOT SOLD SEPARAT | CONPISTON |
| 152. | NSS | [18] | NOT SOLD SEPARAT | CONSHOE |
| 153. | NSS | [2] | NOT SOLD SEPARAT | CONPLATE |
| 156. | NSS | [2] | NOT SOLD SEPARAT | CONBUSHING, BALL |
| 157. | 2441U436S157 | [8] | SPRING | KOBCONED DISK |
| 158. | 2441U436S158 | [4] | SHIM | KOB |
| 212. | NSS | [2] | NOT SOLD SEPARAT | CONPLATE |
| 251. | NSS | [2] | NOT SOLD SEPARAT | CONBRACKET |
| 253. | NSS | [4] | NOT SOLD SEPARAT | CONMETAL |
| 254. | NSS | [4] | NOT SOLD SEPARAT | CONCLUMP |
| 255. | NSS | [4] | NOT SOLD SEPARAT | CONCLUMP |
| 261. | 2441U717S261 | [1] | COVER | COVER |
| 262. | 2441U436S262 | [1] | COVER | COVER |
| 271. | 2437U182S271 | [1] | BELT CASING (F) | BELT CASING (F) |
| 272. | 2437U182S272 | [1] | BELT CASING (R) | BELT CASING (R) |
| 273. | 2441U436S273 | [2] | RETAINER | KOB |
| 274. | 2437U172S274 | [1] | RIGID TUBE | KOB(F) |
| 278. | 2441U436S278 | [1] | RIGID TUBE | KOB(R) |
| 280. | 2441U436S280 | [2] | BOLT | KOB |
| 312. | 2437U172S312 | [1] | BLOCK, VALVE | BLOCK, VALVE |
| 313. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, VALVE (R) |
| 314. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, VALVE (L) |
| 315. | 2441U436S315 | [2] | GUIDE RING | KOB |
| 402. | ZS23C06020 | [8] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm Superseded by part number: ZS28C06020 |
| 403. | 2437U172S403 | [8] | CAPSCREW | CAPSCREW |
| 405. | ZS23C06045 | [8] | CAPSCREW,Hex Socket Head, M6 x 45mm | KOBSCREW M06x1.0x45mm |
| 406. | ZS23C06016 | [8] | SCREW,Hex Socket Head, M6 x 16mm | KOBM06x1.0x16mm Superseded by part number: ZS28C06016 |
| 410. | ZS23C08025 | [4] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 413. | ZS23C08020 | [8] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 416. | ZS23C10030 | [16] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm Superseded by part number: ZS28C10030 |
| 418. | ZS23C10040 | [4] | SCREW,Hex Socket Head, M10 x 40mm | KOBM10x1.50x40mm |
| 431. | ZS23C18040 | [8] | CAPSCREW M18x2.50x40mm | CAPSCREW M18x2.50x40mm |
| 455. | NSS | [8] | NOT SOLD SEPARAT | CONBOLT |
| 466. | 2436U1745S253 | [4] | PLUG | KOB |
| 469. | 2441U413S474 | [3] | PLUG | KOB |
| 473. | 2436U368S151 | [2] | PLUG | KOB |
| 474. | 2453U194S474 | [2] | PLUG | |
| 490. | 2438U1538S490 | [39] | PLUG | PLUG |
| 492. | ZE82T02000 | [2] | PLUG | KOBPipe, 1.25" PT |
| 494. | 2437U172S494 | [2] | PLUG | |
| 527. | 2441U436S527 | [2] | CASTING CASING | CASTING CASING |
| 531. | 2441U436S531 | [2] | LEVER | KOB |
| 532. | 2441U436S532 | [2] | PISTON | KOBPISTON, SURBO |
| 534. | 2441U436S534 | [2] | STOP | KOB(L) |
| 535. | 2441U436S535 | [2] | STOPPER (S) | STOPPER (S) |
| 543. | 2441U436S543 | [2] | RING | KOB |
| 544. | 2441U436S544 | [2] | SCREW | KOB |
| 545. | 2441U436S545 | [2] | PIN | KOB |
| 551. | 2437U182S551 | [2] | CASING | KOBCASING |
| 572. | 2441U436S572 | [2] | COVER | KOB |
| 615. | 2441U436S615 | [2] | LEVER | KOB |
| 617. | 2441U436S617 | [2] | PIN | KOB |
| 620. | 2441U436S620 | [2] | PIN | KOB |
| 629. | 2441U436S629 | [2] | LEVER | KOB |
| 631. | NSS | [2] | NOT SOLD SEPARAT | CONCASING |
| 632. | NSS | [2] | NOT SOLD SEPARAT | CONCOVER |
| 633. | NSS | [2] | NOT SOLD SEPARAT | CONCASING |
| 634. | NSS | [2] | NOT SOLD SEPARAT | CONPISTON |
| 635. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| 636. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING |
| 637. | NSS | [2] | NOT SOLD SEPARAT | CONPISTON |
| 638. | NSS | [2] | NOT SOLD SEPARAT | CONSPOOL |
| 639. | NSS | [2] | NOT SOLD SEPARAT | CONSEAT, SPRlNG |
| 640. | NSS | [2] | NOT SOLD SEPARAT | CONSLEEVE |
| 641. | NSS | [2] | NOT SOLD SEPARAT | CONSETSCREW |
| 646. | NSS | [2] | NOT SOLD SEPARAT | CONSEAT, SPRING |
| 649. | NSS | [2] | NOT SOLD SEPARAT | CONNUT |
| 651. | NSS | [2] | NOT SOLD SEPARAT | CONSPOOL |
| 653. | NSS | [2] | NOT SOLD SEPARAT | CONSLEEVE |
| 655. | 2437U182S655 | [2] | SPRING | KOBSPRING |
| 656. | 2437U182S656 | [2] | SPRING | KOB |
| 658. | 2437U182S658 | [2] | SPRING | KOB |
| 661. | 2441U436S661 | [2] | STOP | KOB |
| 662. | 2441U436S662 | [2] | LINER | KOB |
| 663. | 2483U235S663 | [2] | SPRING SEAT | KOB |
| 664. | 2441U491S664 | [4] | SPRING SEAT | KOB |
| 667. | 2437U182S667 | [2] | PISTON | KOBPISTON |
| 669. | 2441U436S669 | [2] | PISTON | KOBPISTON |
| 672. | 2441U436S672 | [2] | COVER | COVER |
| 701. | ZD12G02500 | [2] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 702. | ZD12G03000 | [10] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 714. | ZD12G13000 | [2] | O-RING,129.40mm ID x 135.60mm OD x 3.10mm | KOBID 129.40 ± 1.05 x OD 135mm |
| 722. | ZD12P00600 | [15] | O-RING | KOBID 05.80 ± 0.15 x OD 09mm |
| 724. | ZD12P00800 | [4] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 725. | ZD12P01000 | [2] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 728. | ZD12P01800 | [6] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 731. | ZD12P02290 | [2] | O-RING | KOB |
| 732. | ZD12P01600 | [4] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 733. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 734. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 735. | ZD12P01200 | [6] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 746. | 2441U333S746 | [2] | O-RING | KOB |
| 754. | ZD12P00300 | [2] | O-RING | KOB |
| 755. | ZD12P01100 | [4] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 774. | 2437U172S774 | [1] | OIL SEAL | KOB Superseded by part number: 2441U267S774 |
| 793. | 2441U475S793 | [4] | WASHER, SEALING | KOBWASHER, SEAL Superseded by part number: 2441U436S793 |
| 801. | ZN11C08005 | [4] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08005 |
| 810. | 2441U436S810 | [4] | NUT | KOB |
| 833. | ZR16X04000 | [2] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 885. | 2441U354S143 | [2] | PIN | KOB |
| 886. | 2441U436S886 | [2] | PIN | KOB |
| 924. | 2441U436S924 | [4] | SCREW | KOBSET Superseded by part number: 2441U722S924 |
| 926. | 2441U436S926 | [2] | SET OF SCREWS | KOB |
| 927. | 2441U436S927 | [4] | SET OF SCREWS | KOB |
| 930. | 2437U182S930 | [2] | SPRING | |
| 938. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| . . | 2437U172S11 | [1] | PISTON | KOBREPAIR KIT, CONSISTS OF REF 151, 152 Superseded by part number: YN10V00003S011 |
| . . | 2437U172S18 | [1] | PLATE | KOBREPAIR KIT, CONSISTS OF REF 153, 156 |
| . . | 2437U172S36 | [1] | CONTROL | KOBREPAIR KIT, CONSISTS OF REF 212, 251, 253 - 255, 455 & 938 |
| . . | 2437U172S83 | [1] | SLEEVE | KOBREPAIR KIT, CONSISTS OF REF 651, 653 |
| . . | 2437U182S13 | [1] | CYLINDER | KOBREPAIR KIT, CONSISTS OF REF 141, 313 |
| . . | 2437U182S14 | [1] | CYLINDER | KOBREPAIR KIT, CONSISTS OF REF 141, 314 |
| . . | 2437U182S51 | [1] | X | KOBREPAIR KIT, CONSISTS OF REF 402, 403, 406, 494, 629, 631 - 634, 646, 647, 701, 702, 801, 886 & 924 |
