纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (310-01[03]) - HARNESS ASSY, UPP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
489 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF13E00008F1 | [1] | Harness Assy, Upp, Serial Range: LF05-04001-LF05-04212 | |
| . . | LF13E00008F2 | [1] | Harness Assy, Upp, Start Serial: LF05-04213 | |
| 1. | LF13E01042P1 | [1] | Harness (upp), Start Serial: LF05-04001 | |
| . . | LF13E01042P2 | [1] | Harness (upp), Start Serial: LF05-04213 | |
| 2. | YT13E01145P2 | [1] | ELECTRIC CABLE | KOB |
| 2-3. | LQ13E01099S002 | [1] | FUSE | KOBFusible Link |
| 3. | YT13E01142P1 | [1] | ELECTRIC CABLE | KOB |
| 4. | YT13E01143P1 | [1] | ELECTRIC CABLE | KOB |
| 5. | YT13E01144P2 | [1] | ELECTRIC CABLE | KOB |
| 6. | LE13E01006P1 | [1] | HARNESS | KOBCable |
| 7. | YT13E01127P1 | [1] | BRACKET | KOBBracket |
| 8. | YT13E01148P1 | [1] | BRACKET | KOBBracket |
| 9. | YE13E01046P1 | [1] | PLATE | KOB |
| 10. | EW02E01015D9 | [8] | CLIP,20mm ID, P Type | KOB, Serial Range: LF05-04001-LF05-04212 |
| 11. | EW02E01015D4 | [2] | CLIP | KOB |
| 12. | ZM61C06016 | [1] | BOLT | KOBSems |
| 13. | EW02E01015DD | [2] | CLIP | KOB |
| 15. | PY01P01043D3 | [90] | CABLE TIE,188mm L | KOB, Serial Range: LF05-04001-LF05-04212 |
| 16. | PY01P01043D8 | [8] | CABLE TIE,102mm L | KOB |
| 17. | YN13E01375P1 | [29] | CLIP,M8 x 8.20mm Shank | KOB |
| 18. | ZC46X46014 | [2] | CLIP | KOB |
| 22. | ZM73C08016 | [13] | BOLT,M8x16mm - Course Thread | KOBSems |
| 23. | ZM73C10020 | [15] | BOLT,M10x20mm - Course Thread | KOBSems |
| 27. | ZW16P06000 | [1] | WASHER | KOB |
| 30. | EW02E01016D8 | [1] | CLIP | KOB |
| 32. | ZN18C05004 | [1] | NUT | KOB |
| 34. | ZW16P05000 | [3] | WASHER | KOB |
| 35. | ZS18C06012 | [1] | SCREW,Hex, M6 x 12mm | KOBCap |
| 36. | ZW26X06000 | [1] | LOCK WASHER | KOB |
| 37. | ZS16C05012 | [2] | CAPTIVE WASHER SCREW | KOBCap |
| 38. | ZW26X05000 | [2] | LOCK WASHER | KOBLock |
| 39. | EW02E01015DF | [1] | CLIP | KOBClip, Serial Range: LF05-04001-LF05-04212 |
| 40. | EW02E01015D6 | [1] | CLIP | KOB |
| 41. | LC13E01330P1 | [1] | GROMMET | KOB |
| 42. | PY01P01043DA | [12] | CABLE TIE,2.50mm W x 205mm L | KOB |
| 43. | YT13E01161P1 | [1] | Harness, Serial Range: LF05-04001-LF05-04212 | |
| 44. | YT11E01043P1 | [3] | SPRING | SMClip |
| 45. | LF13E01043P1 | [1] | HARNESS | KOB, Start Serial: LF05-04213 Superseded by part number: LF13E01043P2 |
| A1. | YT03Z00027P1 | [1] | Schematic, Elec [ NOT IN SETVICE] | |
