凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (77.100.XX[17]) - ARM CAM AUGER HYDRAULIC 555/580 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
881 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47455778
|
[1] |
LINKAGE
|
SAS
Cam Arm
|
| 2. |
47532859
|
[1] |
SLIDER
|
SAS
Link Auger
|
| 3. |
47534242
|
[1] |
LATCH
|
SAS
Cam Arm
|
| 4. |
120070
|
[1] |
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
|
NH
|
| 5. |
100037
|
[1] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 6. |
1319740C2
|
[1] |
PIN,3mm OD x 20mm OAL
|
IH
|
| 7. |
87000071
|
[1] |
COMPRESSION SPRING,47.2mm Free Length
|
GI
Superseded by part number: 540815R2
|
| 8. |
87455
|
[1] |
SLOTTED PIN,1/8" OD x 1" OAL
|
WIN
Superseded by part number: 84818466
|
