现代零件查询R55-7A GEAR PUMP(4/4, AP2D28)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
586 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
XJDD-01034
|
[1] |
GEAR PUMP
|
|
| 1. |
XJDD-00077
|
[1] |
FRAME
|
|
| 2. |
XJDD-00860
|
[1] |
HOUSING
|
|
| 3. |
XJDD-00861
|
[1] |
GEAR
|
|
| 4. |
XJDD-00862
|
[1] |
GEAR
|
|
| 5. |
XJDD-00081
|
[1] |
THRUST PLATE ASSY
|
|
| 6. |
XJDD-00082
|
[4] |
METAL
|
|
| 7. |
XJDD-00083
|
[1] |
RING-BACK UP
|
|
| 8. |
XJDD-00084
|
[2] |
PIN-PARALLEL
|
|
| 9. |
XJDD-00085
|
[1] |
RING-SQUARE
|
|
| 10. |
XJDD-00863
|
[1] |
COUPLING
|
|
| 11. |
XJDD-00087
|
[1] |
RETAINING RING(C TYPE)
|
|
| 12. |
XJDD-00864
|
[4] |
SCREW-HEX SO HD CAP
|
|
| 13. |
XJDD-00089
|
[1] |
O-RING
|
|
