| . . | 24100J9397F4 | [1] | REMOTE-CONTROL ASSY | |
| 1. | R18P0168D29 | [1] | FLEXIBLE HOSE | KOB |
| 2. | ZC15X03300 | [4] | CLIP | KOB |
| 3. | 2418P10004 | [1] | TUBE | KOB |
| 4. | ZA23F22012 | [1] | HYD CONNECTOR | KOB3/4"PF - M30x1.50 x 46mm Long |
| 5. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 6. | 2444Z2296 | [1] | HYD CONNECTOR | KOB |
| 7. | 2436U1171D31 | [2] | CHECK VALVE | KOB, Serial Range: YQ0101-YQ0133 |
| . . | 2436U1171D31 | [1] | CHECK VALVE | KOB, Start Serial: YQ0134 |
| 8. | 2444Z2892 | [1] | TEE | KOB(Incls. O-Ring ZD12P01400) |
| 9. | ZH22X06000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400), Serial Range: YQ0101-YQ0133 |
| 10. | 2444R963D11 | [1] | FLEXIBLE HOSE | KOB550 mm long (21-21/32 in), Serial Range: YQ0101-YQ0564 Superseded by part number: HX31E04055DX |
| 11. | 2445R373F1 | [1] | ACCUMULATOR | KOB |
| 12. | 2416T20884 | [1] | BRACKET | |
| 13. | 2444Z3136 | [1] | CROSS | |
| 14. | 2444Z3134 | [1] | TEE | KOB1/4" PF x 40mm Long |
| 15. | ZW22X10000 | [3] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 16. | 2444Z3133 | [1] | TEE | KOB, Serial Range: YQ0101-YQ0133 |
| 17. | 2444Z2489 | [1] | HYD CONNECTOR | KOB |
| 18. | 2444Z2358 | [1] | TEE | TEE |
| 19. | 2420R537D054 | [1] | FLEXIBLE HOSE,9.60mm ID x 540mm L | KOB Superseded by part number: 2420R537D055 |
| 21. | 2436R680F1 | [1] | VALVE PRESSURE RELIE | KOB |
| 22. | 2446R151F1 | [1] | ELEMENT | KOBFILTER, LINE ASSY Superseded by part number: 2446R183F1 |
| 22-1. | 2446R151S1 | [1] | HEAD | KOB |
| 22-2. | R36P0019 | [1] | HYDRAULIC OIL FILTER | KOBELEMENT |
| 22-3. | 45Z91D84 | [1] | O-RING | KOBID 56.74 ± 0.25 OD 63.80mm |
| 22-4. | 2446R151S4 | [1] | RING | KOBBACK-UP |
| 22-5. | 2446R151S5 | [1] | CASE | KOB |
| 23. | 2444Z3145 | [1] | TEE | KOB |
| 24. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 25. | ZS13C08055 | [1] | SCREW | KOBM08x1.25x55mm Superseded by part number: ZS18C08055 |
| 26. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 27. | 2436U1171D36 | [1] | CHECK VALVE | KOB |
| 28. | ZH31M08004 | [3] | ELBOW | KOB |
| 29. | 2436U1170F1 | [1] | CONTROL VALVE | KOBPRESS |
| 30. | ZS13C06014 | [4] | CAPSCREW | |
| 31. | ZW22X06000 | [6] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 32. | 2444Z2335 | [4] | CONNECTION | KOB |
| 33. | ZH22X04000 | [7] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 34. | 2420R349D040 | [2] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 35. | ZX15K08060 | [1] | TUBE | KOB |
| 36. | 2420R537D120 | [1] | HOSE ASSY.,9.60mm ID x 1200mm L | KOB1200mm Long (47-1/4 in) Superseded by part number: HX21E06120DX |
| 37. | 2420R349D080 | [1] | HOSE,6.35mm ID x 800mm L | KOB800mm Long (31-1/2 in) |
| 38. | 2420R349D050 | [2] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 39. | 2420R349D032 | [1] | FLEXIBLE HOSE | KOB320mm Long (12-19/32 in) Superseded by part number: 2420R349D035 |
| 40. | 2420R349D150 | [1] | HOSE,6.35mm ID x 1500mm L | KOBPF 1/4 |
| 41. | 2444R963D1 | [1] | FLEXIBLE HOSE | KOB750mm Long (29-1/2 in), Serial Range: YQ0101-YQ0564 |
| . . | 2444R963D1 | [2] | FLEXIBLE HOSE | KOB750mm Long (29-1/2 in), Start Serial: YQ0565 |
| 42. | 2444Z2336 | [1] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 43. | ZH32X04000 | [9] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004), Serial Range: YQ0101-YQ0227 |
| 44. | 2444T2580 | [1] | TEE | KOB3/8" PF x 61mm Long (No O-Ring supplied) |
| 45. | 2420R349D075 | [1] | HOSE | KOB750mm Long (29-1/2 in) Superseded by part number: 2444R3019D3 |
| 46. | ZH31M08006 | [3] | ELBOW | KOB |
| 47. | 2444R963D2 | [1] | FLEXIBLE HOSE | KOB1800mm Long (70-7/8 in) |
| 48. | ZH52X06000 | [1] | TEE,30 Degree Fl, Male, PF 3/8" x 3/8" x 3/8", O-Ring | KOB3/8"PFx54mm Long (Incls. O-Ring ZD12P01400) |
| 49. | 2444Z2448F3 | [1] | HYD CONNECTOR | KOBASSY |
| 50. | ZX15K08110 | [1] | KIT | KOBNYLON, Serial Range: YQ0101-YQ0227 |
| 51. | 2420R537D150 | [1] | FLEXIBLE HOSE,9.60mm ID x 1500mm L | KOB3/8" PF, 1500mm Long (59-1/16 in), Serial Range: YQ0101-YQ0156 Superseded by part number: HX21E06150DX |
| 52. | ZX15K08005 | [1] | TUBE | KOB, Serial Range: YQ0101-YQ0227 |
| 53. | ZX15K08055 | [2] | TUBE NYLON, Serial Range: YQ0101-YQ0227 | TUBE NYLON, Serial Range: YQ0101-YQ0227 |
| 54. | 2420R537D210 | [1] | HOSE,9.53mm ID x 2100mm L | KOB, Serial Range: YQ0101-YQ0156 |
| 55. | 2420R537D170 | [3] | HOSE,9.60mm ID x 1700mm L | KOB, Serial Range: YQ0101-YQ0156 |
| . . | 2420R537D170 | [1] | HOSE,9.60mm ID x 1700mm L | KOB, Start Serial: YQ0157 |
| 56. | 2420R537D140 | [1] | HOSE ASSY.,9.60mm ID x 1400mm L | KOB1400mm Long (55-7/64 in), Serial Range: YQ0101-YQ0156 |
| 57. | 2444R941D9 | [1] | FLEXIBLE HOSE | KOB800mm Long (31-1/2 in) |
| 58. | ZH32X06000 | [5] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 61. | 2420R537D075 | [1] | HOSE,9.60mm ID x 750mm L | KOB |
| 62. | ZX15K08130 | [1] | FLEXIBLE HOSE | KOB, Serial Range: YQ0101-YQ0227 |
| 63. | 2444Z3163 | [4] | HYD CONNECTOR | KOBCONNECTOR ADAPTER Superseded by part number: 2444Z3178D2 |
| 64. | ZH51K08000 | [3] | TEE | KOB, Serial Range: YQ0101-YQ0227 |
| . . | ZH51K08000 | [1] | TEE | KOB, Start Serial: YQ0228 |
| 65. | 2444Z3164 | [1] | CONNECTOR | CONNECTOR |
| 66. | ZX15K08095 | [1] | TUBE | KOBNYLON |
| 67. | ZX15K08065 | [1] | TUBE | KOB, Serial Range: YQ0101-YQ0227 |
| 68. | 2420R537D180 | [1] | HOSE,9.60mm ID x 1800mm L | KOB1800mm Long (70-7/8 in), Serial Range: YQ0101-YQ0156 |
| 69. | 2420R537D155 | [1] | HOSE,9.53mm ID x 1550mm L | KOB1550mm Long (61-1/64 in), Serial Range: YQ0101-YQ0156 |
| 70. | 2444Z2432 | [1] | TEE | KOB1/4" PF x (2) 3/8" PF x 52mm Long (Incls. O-Ring ZD12P01400), Start Serial: YQ0134 |
| 71. | ZX15K08090 | [2] | FLEXIBLE HOSE | KOBNYLON |
| 72. | ZH21M08006 | [3] | HYD CONNECTOR | KOB |
| 73. | 2444Z2345 | [1] | 90 ELBOW | KOB90° -- (Incls. O-Rings ZD12P01400 & ZD12P01800) |
| 74. | 2444Z2338 | [1] | 90 ELBOW | KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100) |
| 75. | ZH21M08004 | [6] | HYD CONNECTOR | KOB, Serial Range: YQ0101-YQ0227 |
| . . | ZH21M08004 | [4] | HYD CONNECTOR | KOB, Start Serial: YQ0228 |
| 76. | 2410T323 | [1] | BLOCK | KOB |
| 77. | ZS13C08040 | [2] | SCREW | KOBM08x1.25x40mm Superseded by part number: ZS18C08040 |
| 78. | ZW22X08000 | [8] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 79. | 2420R349D085 | [2] | HOSE,6.35mm ID x 850mm L | KOB850mm Long (33-29/64 in) |
| 80. | 2420R537D036 | [1] | HOSE,9.60mm ID x 360mm L | KOB, Serial Range: YQ0101-YQ0227 Superseded by part number: 2420R537D040 |
| 81. | 2444T2505 | [1] | HYD CONNECTOR | KOB1/4" PF - 3/8" PF x 35mm Long (Incls. O-Ring ZD12P01400) |
| 82. | ZH52X04000 | [2] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004), Serial Range: YQ0101-YQ0227 |
| . . | ZH52X04000 | [3] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004), Start Serial: YQ0228 |
| 83. | 2444Z2333 | [1] | TEE | KOB |
| 84. | 2420Z1188 | [3] | GROMMET | KOB |
| 85. | 2432Z290 | [20] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 86. | 2444T2501D1 | [1] | TEE | KOB |
| 87. | 2444R974D3 | [2] | FLEXIBLE HOSE | KOB |
| 88. | ZX15K08012 | [1] | TUBE | KOBNYLON, Serial Range: YQ0101-YQ0564 |
| . . | ZX15K08015 | [1] | KIT | KOBNYLON, Start Serial: YQ0565 |
| 89. | 2444Z244BF1 | [2] | CONNECTOR ASSY | |
| 90. | 2444Z2477F1 | [2] | HYD CONNECTOR | KOBASSY |
| 91. | 2420R564 | [1] | GROMMET | KOB |
| 92. | 2418T18241 | [1] | TUBE | KOB, Serial Range: YQ0101-YQ0280 |
| 93. | 2420R537D045 | [1] | HOSE,9.60mm ID x 450mm L | KOB, Start Serial: YQ0134 Superseded by part number: HX21E06045DX |
| 94. | ZA23F10004 | [1] | HYD CONNECTOR | KOB1/4" PF x M16x1.50 x 33mm Long, Serial Range: YQ0101-YQ0227 |
| . . | ZA23F10004 | [3] | HYD CONNECTOR | KOB1/4" PF x M16x1.50 x 33mm Long, Start Serial: YQ0228 |
| 95. | ZA23F10006 | [1] | HYD CONNECTOR | KOB |
| 96. | 2436U1314F1 | [1] | VALVE | KOBASSY, SOLENOID |
| 97. | 2436U1240F1 | [1] | SOLENOID VALVE | KOBASSY |
| 98. | 2444Z2337 | [10] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 99. | ZS13C08020 | [4] | SCREW | KOBM08x1.25x20mm Superseded by part number: ZS18C08020 |
| 100. | 2444T2533 | [1] | TEE | KOB(Incls. O-Ring ZD12P01400) Superseded by part number: 87635046 |
| 101. | 2418T16418 | [1] | PLATE | PLATE |
| 102. | ZS13C10025 | [3] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 104. | 2418T18241D2 | [1] | TUBE, Start Serial: YQ0281 | |
| 105. | ZX15K08045 | [1] | TUBE | KOB |
| 106. | ZS13C06016 | [2] | SCREW | KOBM06x1.0x16mm |
| 107. | 2420R349D230 | [1] | HOSE ASSY. | KOB2300mm Long (90-1/2 in) |
| 108. | 2420R349D210 | [1] | FLEXIBLE HOSE | KOB2100mm Long (82-11/16 in) |
| 109. | 2420R349D140 | [1] | HOSE,6.35mm ID x 1400mm L | KOB1/4" PF |
| 110. | 2444T3322 | [1] | TEE | KOB |
| 111. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm, Serial Range: YQ0101-YQ0227 |
| . . | ZD12P01100 | [3] | O-RING | KOBID 10.8mm x OD 13.2mm, Start Serial: YQ0228 |
| 112. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 114. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 115. | 2436U1282D2108 | [1] | VALVE PRESSURE RELIE | KOB |
| 117. | 2444T2524D2 | [1] | HYD CONNECTOR | KOB1/4" PF x 46mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72961286 |
| 119. | 2444T3298 | [1] | TEE | KOB3/8" PF - 1/4" PF (Incls. O-Ring ZD12P01100) |
| 120. | 2444Z2901 | [1] | ELBOW | KOB90° |
| 121. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 122. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm, Start Serial: YQ0281 Superseded by part number: 86588450 |
| 123. | 2444Z2447F1 | [2] | ELBOW UNION | KOBUnion Elbow ASSY |
| 124. | ZS23C06030 | [8] | SCREW,Hex Socket Head, M6 x 30mm | KOBM06x1.0x30mm |
| 126. | 2444Z2434 | [1] | CONNECTOR, Serial Range: YQ0101-YQ0156 | CONNECTOR, Serial Range: YQ0101-YQ0156 |
| 127. | 2444Z2435 | [1] | HYD CONNECTOR | KOB, Serial Range: YQ0101-YQ0156 |
| 128. | 2444Z2436 | [1] | CONNECTOR YQ0101 to YQ0156 | CONNECTOR YQ0101 to YQ0156 |
| 129. | 2444Z2437 | [1] | CONNECTOR, Serial Range: YQ0101-YQ0156 | CONNECTOR, Serial Range: YQ0101-YQ0156 |
| 130. | 2444Z2440 | [1] | HYD CONNECTOR | KOB, Serial Range: YQ0101-YQ0156 |
| 131. | 2444Z2441 | [1] | HYD CONNECTOR | KOB, Serial Range: YQ0101-YQ0156 |
| 132. | 2444Z2438 | [1] | CONNECTOR, Serial Range: YQ0101-YQ0156 | CONNECTOR, Serial Range: YQ0101-YQ0156 |
| 133. | 2444Z2439 | [1] | CONNECTION | KOB, Serial Range: YQ0101-YQ0156 |
| 138. | 2414U167 | [2] | BOOT | KOB |
| 139. | 2444R974D2 | [1] | HOSE | KOB |
| 140. | 2444Z2548 | [2] | HYD CONNECTOR | KOB |
| 141. | 2444T2592 | [2] | TEE | KOB3/8" PF - 1/4" PF (No O-Ring supplied) |
| 143. | 2420T3483 | [4] | GROMMET | KOB |
| 144. | 2444Z2535 | [2] | HYD CONNECTOR | KOB |
| 145. | 2444Z2526 | [1] | TEE | KOB |
| 146. | 2425Z519 | [2] | BALL | KOB |
| 147. | 2444Z2446 | [2] | ELBOW | KOB |
| 148. | 2444Z2482 | [1] | TEE | KOB |
| 149. | ZW11K06000 | [8] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 150. | 2444R963D10 | [1] | HOSE | KOB420mm Long (16-1/2 in) Superseded by part number: 2444R963D26 |
| 151. | 2420R537D200 | [2] | HOSE,9.60mm ID x 2000mm L | KOB, Serial Range: YQ0101-YQ0156 |
| 152. | 2420R349D065 | [2] | HOSE,650.00 mm | KOB650mm Long (25-1/2 in), Serial Range: YQ0101-YQ0227 Superseded by part number: HX21E04065DX |
| . . | 2420R349D065 | [3] | HOSE,650.00 mm | KOB650mm Long (25-1/2 in), Start Serial: YQ0228 Superseded by part number: HX21E04065DX |
| 153. | 2444Z2541 | [1] | HYD CONNECTOR | KOB |
| 154. | ZW22K06000 | [8] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 155. | 2444Z2546F1 | [1] | HYD CONNECTOR | KOBASSY |
| 156. | 2420R537D100 | [8] | HOSE,9.60mm ID x 1000mm L | KOB, Serial Range: YQ0101-YQ0156 |
| 157. | ZN18C14011 | [2] | NUT | KOBM14x2.0mm |
| 158. | 2444Z2544 | [1] | TEE | KOB1/4"PTx60mm Long (No O-Ring supplied) |
| 159. | 2444Z2461 | [1] | TEE | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 160. | 2436U1295D2150 | [1] | CHECK VALVE | KOB |
| 161. | 2444T2529 | [1] | TEE | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 162. | 2444Z2889 | [1] | HYD CONNECTOR | KOB |
| 163. | 2406R256F1 | [2] | HANDLE | KOBASSY |
| 164. | 2436U1287F1 | [2] | PILOT VALVE | KOB Superseded by part number: 2436U1287F3 |
| 165. | 2420R537D245 | [1] | FLEXIBLE HOSE,9.60mm ID x 2450mm L | KOB, Start Serial: YQ0157 |
| 166. | 2420R537D240 | [2] | HOSE,9.53mm ID x 2400mm L | KOB, Start Serial: YQ0157 |
| 167. | 2420R537D290 | [1] | HOSE,9.53mm ID x 2900mm L | KOB, Start Serial: YQ0157 |
| 168. | 2420R537D270 | [1] | FLEXIBLE HOSE,9.60mm ID x 2700mm L | KOB2700mm Long (106-19/64 in), Start Serial: YQ0157 |
| 169. | 2420R537D265 | [1] | FLEXIBLE HOSE,9.60mm ID x 2650mm L | KOB, Start Serial: YQ0157 |
| 170. | 2420R537D310 | [1] | FLEXIBLE HOSE,9.60mm ID x 3100mm L | KOB, Start Serial: YQ0157 |
| 171. | 2420R537D260 | [1] | HOSE,9.60mm ID x 2600mm L | KOB, Start Serial: YQ0157 |
| 172. | ZH51M08006 | [1] | TEE | KOB, Start Serial: YQ0228 |
| 173. | 2418T16720 | [1] | RIGID TUBE | KOB, Start Serial: YQ0228 |
| 174. | ZX15K08180 | [1] | TUBE | KOBNYLON, Start Serial: YQ0228 |
| 175. | ZX15K08075 | [1] | FLEXIBLE HOSE | KOB, Start Serial: YQ0228 |
| 176. | ZX15K08270 | [1] | TUBE | KOB |
