现代零件查询R55-7A MAIN CONTROL VALVE(3/4)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
679 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
MAIN CONTROL VALVE
|
|
| 10. |
XKBF-00133
|
[1] |
INLET ASSY
|
|
| N10-1. |
XKBF-00183
|
[1] |
BLOCK-WORK
|
|
| 10-2. |
XKBF-00184
|
[1] |
SPOOL-T/STRAIGHT
|
|
| 10-3. |
XKBF-00186
|
[1] |
O-RING
|
|
| 10-4. |
XKBF-00187
|
[1] |
FILTER ASSY
|
|
| 10-5. |
XKBF-00173
|
[1] |
MAIN RELIEF VALVE
|
|
| 10-6. |
XKBF-00188
|
[2] |
PLUG 3 ASSY
|
|
| 10-7. |
XKBF-00160
|
[1] |
CAP-PILOT(B1)
|
|
| 10-8. |
XKBF-00161
|
[4] |
BOLT-WRENCH
|
|
| 10-9. |
XKBF-00162
|
[4] |
WASHER-PLAIN
|
|
| 10-10. |
XKBF-00189
|
[1] |
SEAT-SPRING
|
|
| 10-11. |
XKBF-00190
|
[1] |
SPRING-PILOT
|
|
| 10-12. |
XKBF-00191
|
[1] |
CAP-PILOT(B2)
|
|
| 10-13. |
XKBF-00192
|
[2] |
POPPET-CHECK
|
|
| 10-14. |
XKBF-00193
|
[2] |
SPRING-CHECK
|
|
| 10-15. |
XKBF-00194
|
[2] |
PLUG ASSY
|
|
| 10-16. |
XKBF-00195
|
[2] |
BOLT-WRENCH
|
|
| 11. |
XKBF-00134
|
[1] |
TRAVEL ASSY
|
|
| N11-1. |
XKBF-00196
|
[1] |
BLOCK-WORK
|
|
| 11-2. |
XKBF-00197
|
[1] |
SPOOL ASSY-TRAVEL
|
|
| 11-3. |
XKBF-00146
|
[1] |
PLATE-SEAL
|
|
| 11-4. |
XKBF-00147
|
[1] |
CAP-RETURN
|
|
| 11-5. |
XKBF-00148
|
[2] |
BOLT-WRENCH
|
|
| 11-6. |
XKBF-00149
|
[2] |
BOLT-WRENCH
|
|
| 11-7. |
XKBF-00150
|
[2] |
O-RING
|
|
| 11-8. |
XKBF-00181
|
[1] |
POPPET-CHECK
|
|
| 11-9. |
XKBF-00152
|
[1] |
SPRING-CHECK
|
|
| 11-10. |
XKBF-00182
|
[1] |
PLUG 2 ASSY
|
|
| 11-11. |
XKBF-00154
|
[2] |
WIPER-DUST
|
|
| 11-12. |
XKBF-00178
|
[1] |
OVERLOAD RELIEF VLV
|
|
| 12. |
XKBF-00135
|
[1] |
BOOM 1 ASSY
|
|
| N12-1. |
XKBF-00198
|
[1] |
BLOCK-WORK
|
|
| 12-2. |
XKBF-00199
|
[1] |
SPOOL ASSY-BOOM 1
|
|
| 12-3. |
XKBF-00619
|
[2] |
O-RING(AS568-119)
|
|
| 12-4. |
XKBF-00159
|
[1] |
CAP-PILOT(A)
|
|
| 12-5. |
XKBF-00161
|
[2] |
BOLT-WRENCH
|
|
| 12-6. |
XKBF-00162
|
[2] |
WASHER-PLAIN
|
|
| 12-8. |
XKBF-00151
|
[1] |
POPPET-CHECK
|
|
| 12-9. |
XKBF-00152
|
[1] |
SPRING-CHECK
|
|
| 12-10. |
XKBF-00153
|
[1] |
PLUG 1 ASSY
|
|
| -12A. |
XKBF-00626
|
[1] |
HOLDING VALVE KIT-A
|
|
| 12-11. |
XKBF-00618
|
[1] |
O-RING
|
|
| N12-15. |
XKBF-00628
|
[1] |
PLUG
|
|
| N12-16. |
XKBF-00616
|
[1] |
GUIDE-PISTON
|
|
| N12-17. |
XKBF-00206
|
[1] |
PISTON
|
|
| N12-18. |
XKBF-00207
|
[1] |
PISTON-PILOT
|
|
| N12-19. |
XKBF-00614
|
[1] |
PLUG
|
|
| N12-21. |
XKBF-00209
|
[1] |
BALL-STEEL
|
|
| N12-22. |
XKBF-00210
|
[1] |
COVER-PILOT
|
|
| 12-24. |
XKBF-00081
|
[1] |
O-RING
|
|
| N12-25. |
XKBF-00613
|
[1] |
O-RING
|
|
| N12-26. |
XKBF-00617
|
[1] |
SPRING-PILOT
|
|
| 12-27. |
XKBF-00615
|
[1] |
O-RING
|
|
| 12-31. |
XKBF-00625
|
[1] |
P.WASHER(M6)
|
|
| N12-32. |
XKBF-00624
|
[3] |
BOLT-WRENCH
|
|
| N12-33. |
XKBF-00612
|
[1] |
O-RING
|
|
| -12B. |
XKBF-00627
|
[1] |
HOLDING VALVE KIT-B
|
|
| 12-13. |
XKBF-00202
|
[1] |
POPPET ASSY-HOLDING
|
|
| N12-14. |
XKBF-00203
|
[1] |
POPPET-PILOT
|
|
| N12-20. |
XKBF-00208
|
[1] |
SPRING-H/D
|
|
| N12-28. |
XKBF-00622
|
[1] |
SEAT-SPRING
|
|
| N12-29. |
XKBF-00623
|
[1] |
RING-SNAP
|
|
| N12-30. |
XKBF-00620
|
[1] |
RESTRICTOR-H/D
|
|
| 12-23. |
XKBF-00178
|
[1] |
OVERLOAD RELIEF VLV
|
|
| 16. |
XKBF-00139
|
[3] |
O-RING
|
|
| 17. |
XKBF-00140
|
[3] |
O-RING
|
|
| N. |
@
|
[AR] |
|
|
