现代零件查询R55-7A TRAVEL MOTOR(3/3, JMV-43)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
284 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
TRAVEL MOTOR
|
|
| N -2. |
XKAY-01862
|
[1] |
T/REDUCTION GEAR ASSY
|
|
| 59. |
XKAY-00386
|
[1] |
GEAR-RING
|
|
| 60. |
XKAY-00387
|
[1] |
BEARING-ANGULAR
|
|
| 61. |
XKAY-00388
|
[105] |
BALL-STEEL
|
|
| 62. |
XKAY-00065
|
[2] |
PLUG
|
|
| 63. |
XKAY-00389
|
[1] |
SEAL-FLOATING
|
|
| 64. |
XKAY-00390
|
[1] |
NUT
|
|
| 65. |
XKAY-00391
|
[4] |
WASHER
|
|
| 66. |
XKAY-00392
|
[4] |
COLLAR
|
|
| 67. |
XKAY-00393
|
[4] |
GEAR(A)-PLANETARY
|
|
| 68. |
XKAY-00394
|
[4] |
BEARING-NEEDLE
|
|
| 69. |
XKAY-00395
|
[1] |
PLATE
|
|
| 70. |
XKAY-00396
|
[4] |
BOLT
|
|
| 71. |
XKAY-00397
|
[1] |
GEAR-SUN
|
|
| 72. |
XKAY-00398
|
[1] |
RING-SNAP
|
|
| 73. |
XKAY-00399
|
[1] |
CARRIER
|
|
| 73. |
XKAY-01665
|
[1] |
CARRIER
|
|
| 74. |
XKAY-00400
|
[3] |
PIN-SPRING
|
|
| 74. |
XKAY-01666
|
[3] |
PIN-SPRING
|
|
| 75. |
XKAY-00401
|
[3] |
COLLAR
|
|
| 76. |
XKAY-00402
|
[3] |
GEAR(B)-PLANETARY
|
|
| 77. |
XKAY-00403
|
[3] |
BEARING-NEEDLE
|
|
| 78. |
XKAY-00404
|
[1] |
GEAR-DRIVE
|
|
| 79. |
XKAY-00405
|
[1] |
PLATE-THRUST
|
|
| 80. |
XKAY-00406
|
[1] |
COVER-RING GEAR
|
|
| 81. |
XKAY-00032
|
[3] |
PLUG
|
|
| K82. |
XKAY-00407
|
[1] |
O-RING
|
|
| 83. |
XKAY-00408
|
[12] |
BOLT-WRENCH
|
|
| K. |
XKAY-00413
|
[1] |
SEAL KIT
|
|
