纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (380-17-1[1]) - SHOE ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
352 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT60D00016F2 | [1] | Shoe Assy | |
| . . | YT60D00012F2 | [2] | SHOE | KOBAssy |
| 1. | YT62D00007F1 | [1] | TRACK ASSY | KOBAssy |
| 1-1. | 2424J175D1 | [39] | TRACK LINK | KOB(R. H) |
| 1-2. | 2424J175D2 | [39] | TRACK LINK | KOB(L. H) |
| 1-3. | YT62D01010P1 | [38] | BUSHING | KOB |
| 1-4. | YT62D01002P1 | [38] | PIN | KOB |
| 1-5. | YT62D01003P1 | [1] | BUSHING | KOB |
| 1-6. | YT62D01004P1 | [1] | PIN | KOBMaster |
| 1-7. | YT62D01011P1 | [76] | SEAL | KOB |
| 1-8. | 2418T20891 | [2] | COLLAR | KOB |
| 3. | YT60D00009P1 | [39] | SHOE,600mm W | KOB600mm) |
| 9. | YT60D01001P1 | [156] | BOLT | KOB |
| 11. | YT60D01002P1 | [156] | NUT | KOB |
