凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (80.150.AJ[08]) - FOLDING STAIRS HARDWARE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
689 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47543122
|
[2] |
GUIDE
|
SAS
Track Stairway
|
| 2. |
47667914
|
[1] |
BRACKET
|
SAS
Mount Black With Decal
|
| 3. |
100037
|
[12] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 4. |
22609
|
[2] |
TENSION SPRING
|
FLX
Superseded by part number: 22609\C
|
| 5. |
84156112
|
[2] |
EYEBOLT
|
GI
Adjusting
|
| 6. |
47590740
|
[4] |
SPACER
|
SAS
Guide Track Superseded by part number: 140042
|
| 7. |
120112
|
[8] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 8. |
47543095
|
[1] |
ARM
|
SAS
Stair Pivot
|
| 9. |
86508581
|
[2] |
BOLT,Hex, M12 x 90mm, Cl 8.8
|
NH
|
| 10. |
100038
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 11. |
47814682
|
[2] |
MOUNT
|
SAS
Spring Pivot
|
| 12. |
47543121
|
[2] |
JOURNAL
|
SAS
Pivot
|
| 13. |
86511324
|
[4] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 14. |
47543120
|
[1] |
PLATE
|
SAS
Stairway Travel Left
|
| 15. |
47543119
|
[1] |
PLATE
|
SAS
Stairway Travel Right
|
| 16. |
51200147
|
[2] |
FOOT
|
FLX
Rubber with Steel Washer
|
| 17. |
120100
|
[2] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 18. |
353308
|
[2] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 19. |
GI-844
|
[2] |
ROLLER
|
FLX
Guide
|
| 20. |
87035385
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 35mm, Cl 8.8, Full Thd
|
CAS
|
| 21. |
120069
|
[4] |
BOLT,M10 x 1.5 x 56.58mm OAL, Cl 8.8
|
NH
|
| 22. |
80755
|
[2] |
COTTER PIN,1/8" OD x 1" L
|
NH
|
| 23. |
86625253
|
[4] |
WASHER,11mm ID x 24mm OD x 2mm Thk
|
FAR
|
| 24. |
10717321
|
[4] |
THIN NUT,Thin, M12 x 1.75, Cl 05
|
LEC
Superseded by part number: 100038
|
