现代零件查询R55-7A REMOTE CONTROL LEVEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
867 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31M8-22010
|
[1] |
RCV SUB ASSY-LH
|
|
| . |
31M8-22020
|
[1] |
RCV SUB ASSY-RH
|
|
| 1. |
31M8-22030
|
[1] |
RCV LEVER-LH
|
|
| 1. |
31M8-22040
|
[1] |
RCV LEVER-RH
|
|
| 1-1. |
XKAY-00077
|
[1] |
CASE
|
|
| 1-2. |
XKAY-00065
|
[4] |
PLUG
|
|
| 1-3. |
XKAY-00064
|
[1] |
PLUG
|
|
| K1-4. |
XKAY-00100
|
[1] |
O-RING
|
|
| -1. |
XKAY-00606
|
[1] |
SPOOL KIT
|
|
| 1-5. |
XKAY-00062
|
[2] |
SPOOL
|
|
| 1-6. |
XKAY-00061
|
[AR] |
SHIM
|
|
| 1-7. |
XKAY-00435
|
[2] |
SPRING
|
|
| 1-8. |
XKAY-00436
|
[2] |
SEAT-SPRING(1,3)
|
|
| 1-9. |
XKAY-00058
|
[2] |
STOPPER
|
|
| 1-10. |
XKAY-00437
|
[4] |
SPRING
|
|
| -2. |
XKAY-00608
|
[2] |
PLUG KIT(1,3)
|
|
| 1-11. |
XKAY-00610
|
[2] |
PLUG
|
|
| K1-12. |
XKAY-00611
|
[2] |
SEAL-ROD
|
|
| K1-13. |
XKAY-00438
|
[2] |
O-RING
|
|
| 1-14. |
XKAY-00052
|
[2] |
ROD-PUSH(1,3)
|
|
| -3. |
XKAY-00609
|
[2] |
PLUG KIT(2,4)
|
|
| 1-11. |
XKAY-00610
|
[2] |
PLUG
|
|
| K1-12. |
XKAY-00611
|
[2] |
SEAL-ROD
|
|
| K1-13. |
XKAY-00438
|
[2] |
O-RING
|
|
| 1-15. |
XKAY-00439
|
[2] |
ROD-PUSH(2,4)
|
|
| 1-16. |
XKAY-00075
|
[1] |
PLATE
|
|
| 1-17. |
XKAY-00074
|
[1] |
BUSHING
|
|
| 1-18. |
XKAY-00049
|
[1] |
JOINT ASSY
|
|
| 1-19. |
XKAY-00612
|
[1] |
SWASH PLATE
|
|
| 1-20. |
XKAY-00072
|
[1] |
BOOT
|
|
| 1-21. |
XKAY-00047
|
[1] |
NUT-HEX
|
|
| -4. |
XKAY-00718
|
[1] |
HANDLE KIT-RH
|
|
| -4. |
XKAY-00725
|
[1] |
HANDLE KIT-LH
|
|
| 1-22. |
XKAY-00046
|
[1] |
NUT
|
|
| K1-23. |
XKAY-00440
|
[1] |
O-RING
|
|
| N1-24. |
XKAY-00810
|
[1] |
BAR-HANDLE
|
|
| 1-25. |
XKAY-00811
|
[1] |
NUT
|
|
| 1-26. |
XKAY-00041
|
[1] |
BOOT
|
|
| N1-27. |
XKAY-00719
|
[1] |
HANDLE-RH
|
|
| N1-27. |
XKAY-00720
|
[1] |
HANDLE-LH
|
|
| -5. |
XKAY-00607
|
[1] |
SPOOL KIT(2,4)
|
|
| 1-5. |
XKAY-00062
|
[2] |
SPOOL
|
|
| 1-6. |
XKAY-00061
|
[AR] |
SHIM
|
|
| 1-9. |
XKAY-00058
|
[2] |
STOPPER
|
|
| N1-28. |
XKAY-00441
|
[2] |
SPRING
|
|
| 1-29. |
XKAY-00059
|
[2] |
SEAT-SPRING
|
|
| 2. |
X500-110001
|
[5] |
CONNECTOR-ORFS
|
|
| 3. |
S631-011004
|
[6] |
O-RING
|
|
| 4. |
S621-011001
|
[6] |
O-RING
|
|
| 5. |
31N6-25060
|
[1] |
FILTER-LAST GUARD
|
|
| K. |
91ER-20051
|
[1] |
SEAL KIT
|
|
| N. |
@
|
[AR] |
NOT INDIVIDUALLY SUPPLIED
|
|
