凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (80.150.AJ[14]) - PLATFORM 580 BUSHELL TOW BEHIND Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
882 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47453869
|
[1] |
PLATFORM
|
SAS
Corner Black
|
| 2. |
47458621
|
[1] |
SUPPORT
|
SAS
Platform Black
|
| 3. |
47457704
|
[2] |
PLATFORM
|
SAS
Frame Long Black
|
| 4. |
47615824
|
[1] |
PLATE
|
SAS
Toe Kick Black
|
| 5. |
47452194
|
[4] |
SUPPORT
|
SAS
Platform Mount Black
|
| 6. |
47534143
|
[10] |
U-BOLT,M16 x 2, Square, 180mm W x 175mm L
|
SAS
M16
|
| 7. |
146988
|
[20] |
LOCK NUT,M16 x 2, Cl 8
|
BER
Superseded by part number: 86000441
|
| 8. |
47590160
|
[10] |
U-BOLT
|
SAS
M12
|
| 9. |
86511324
|
[20] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 10. |
9706687
|
[18] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 11. |
100038
|
[38] |
NUT,M12 x 1.75, Cl 8
|
NH
|
