凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (80.150.AJ[16]) - LADDER 760/950 BUSHELL FOR PLATFORM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
900 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47550910
|
[1] |
LADDER
|
SAS
Upper Black
|
| 2. |
47543077
|
[1] |
LADDER
|
SAS
Lower Black
|
| 3. |
47550872
|
[2] |
HANDRAIL
|
SAS
Stairs Black
|
| 4. |
43140
|
[12] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 5. |
100037
|
[12] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 6. |
47550876
|
[1] |
BRACKET
|
SAS
Mounting Black
|
| 7. |
9706687
|
[4] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 8. |
100038
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 9. |
86625253
|
[8] |
WASHER,11mm ID x 24mm OD x 2mm Thk
|
FAR
|
| 12. |
120090
|
[4] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 13. |
146988
|
[4] |
LOCK NUT,M16 x 2, Cl 8
|
BER
Superseded by part number: 86000441
|
