现代零件查询R55-7A DOZER BLADE CYLINDER(W/O VALVE)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
158 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31M8-40033
|
[1] |
DOZER CYLINDER ASSY
|
|
| 1. |
31Y1-24452
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y1-24611
|
[1] |
ROD ASS'Y
|
|
| 3. |
31Y1-26230
|
[1] |
GLAND
|
|
| 4. |
S731-060030
|
[1] |
BUSHING-DU
|
|
| K5. |
Y210-060111
|
[1] |
SEAL-ROD
|
|
| K6. |
Y180-060120
|
[1] |
RING-BACK UP
|
|
| K7. |
Y110-060011
|
[1] |
WIPER-DUST
|
|
| 8. |
Y190-074000
|
[1] |
RING-SNAP
|
|
| K9. |
S632-110001
|
[1] |
O-RING
|
|
| K10. |
S632-105004
|
[1] |
O-RING
|
|
| K11. |
S642-106003
|
[1] |
RING-BACK UP
|
|
| 12. |
31Y1-24491
|
[1] |
PISTON
|
|
| K13. |
S632-060004
|
[1] |
O-RING
|
|
| K14. |
Y420-110000
|
[1] |
SEAL-PISTON
|
|
| K15. |
Y300-110000
|
[1] |
RING-WEAR
|
|
| 16. |
31YC-65310
|
[1] |
NUT-NYLON
|
|
| 17. |
31YC-12030
|
[2] |
BUSHING-PIN
|
|
| 18. |
Y010-055068
|
[4] |
SEAL-DUST
|
|
| 19. |
S652-810002
|
[1] |
NIPPLE-GREASE
|
|
| 20. |
S651-810002
|
[1] |
NIPPLE-GREASE
|
|
| K. |
31Y1-24501
|
[1] |
SEAL KIT
|
|
