凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (80.180.AR[01]) - 435, 460, 580 BUSHEL, HYDRAULIC AUGER HOPPER GEARBOX Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
436 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84497405
|
[1] |
GEARBOX
|
SAS
Deluxe Auger Drive, Complete, Incl 2 - 3, 5 - 13
|
| 2. |
84552584
|
[1] |
HOUSING
|
SAS
Gearbox
|
| 3. |
84470955
|
[4] |
BALL BEARING
|
SAS
SKF 16010
|
| 4. |
86539214
|
[1] |
SHIM
|
NH
Kit, Incl 5 - 7
|
| 5. |
84491593
|
[6] |
SHIM,69mm ID x 79.7mm OD x 0.3mm Thk
|
SAS
|
| 6. |
84491594
|
[2] |
SHIM,69mm ID x 79.7mm OD x 0.4mm Thk
|
SAS
|
| 7. |
84491595
|
[2] |
SHIM,69mm ID x 79.7mm OD x 0.5mm Thk
|
SAS
|
| 8. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
14 Tooth Bevel Gears, Incl in 1
|
| 9. |
370008
|
[2] |
SNAP RING,M50, Ext
|
NH
Superseded by part number: 8603209
|
| 10. |
300633
|
[2] |
SNAP RING,M80, Internal
|
NH
Superseded by part number: 80300633
|
| 11. |
84490921
|
[2] |
SEAL,50mm ID x 80mm OD x 8mm Thk
|
SAS
|
| 12. |
84476580
|
[1] |
SHIELD
|
SAS
Auger Gearbox
|
| 13. |
87034809
|
[1] |
LUBE NIPPLE,45 Degree, 1/4" NPT x .81" lg
|
CAS
Superseded by part number: 80721
|
| 14. |
84527686
|
[1] |
GUIDE
|
SAS
Auger Coupler
|
| 15. |
84424480
|
[1] |
DRIVE
|
SAS
Auger Coupler
|
| 16. |
281069
|
[2] |
BOLT,Hex, 1/4" - 20 x 2 1/2", Gr 8
|
GI
|
| 17. |
20356
|
[2] |
NUT,1/4"-20, GB
|
PA
Superseded by part number: 280129
|
| 18. |
84424488
|
[2] |
KEY
|
SAS
Gearbox Couplers
|
