凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (88.100.55[07]) - KIT, PRESSURE SENSOR 3 BIN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
979 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47722026
|
[1] |
SENSOR
|
SAS
Assy, Incl 2 - 8
|
| 2. |
47843564
|
[3] |
FITTING
|
SAS
Pressure Sensor Assy
|
| 3. |
47502736
|
[6] |
SENSOR
|
SAS
Pressure
|
| 4. |
513309
|
[3] |
HOSE CLAMP,1-1/16" - 2", Worm
|
NH
|
| 5. |
47814496
|
[3] |
WIRE HARNESS
|
SAS
Tank/Meter Pressure
|
| 6. |
47908963
|
[1] |
TOOL
|
SAS
Drill Stepped (Not Shown)
|
| 7. |
47908965
|
[1] |
TOOL
|
SAS
Tapered (Not Shown)
|
| 8. |
87557086
|
[25] |
CABLE TIE
|
SAS
(Not Shown)
|
