现代零件查询R55-7A PILOT HYD PIPING 1 (B/SWING)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
825 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 10. |
31M8-20121
|
[1] |
CROSS ASSY
|
|
| 10-1. |
31M8-20160
|
[2] |
CROSS-BULKHEAD TYPE
|
|
| 11. |
31M6-51061
|
[2] |
SHIM(3.2T)
|
|
| 14. |
P920-042012
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 27. |
P920-042024
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 28. |
P920-042025
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 29. |
P920-042024
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 30. |
P920-042034
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 31. |
P930-042009
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 33. |
P930-042012
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 36. |
P930-042017
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 47. |
X500-110001
|
[2] |
CONNECTOR-ORFS
|
|
| 51. |
X520-110001
|
[1] |
ELBOW-90,ORFS
|
|
| 56. |
X850-515100
|
[1] |
ELBOW-90,SWIVEL,ORFS
|
|
| 57. |
X820-045151
|
[3] |
TEE-R/TYPE,ORFS
|
|
| 63. |
X710-100102
|
[1] |
CAP-HYD,ORFS
|
|
| 66. |
S621-011001
|
[14] |
O-RING
|
|
| 68. |
S631-011004
|
[6] |
O-RING
|
|
| 74. |
S035-063046
|
[8] |
BOLT-W/WASHER
|
|
| 76. |
S037-102526
|
[1] |
BOLT-W/WASHER
|
|
