现代零件查询R75-7 CRANKCASEEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
706 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJAF-01752
|
[1] |
CRANKCASE ASSY
|
|
| N2. |
@
|
[1] |
CRANKCASE SUB ASSY
|
|
| 3. |
XJAF-00190
|
[10] |
CAP-SEALING
|
|
| N4. |
@
|
[4] |
CAP-MATAL
|
|
| N5. |
@
|
[1] |
CAP-MATAL,REAR
|
|
| 6. |
XJAF-00605
|
[10] |
BOLT-BEARING CAP
|
|
| N7. |
@
|
[1] |
CRANKCASE
|
|
| 8. |
XJAF-00189
|
[6] |
CAP-SEALING
|
|
| N9. |
@
|
[3] |
PLUG
|
|
| 11. |
XJAF-00198
|
[1] |
PLUG-CAM
|
|
| 12. |
XJAF-00607
|
[2] |
PIN-DOWEL
|
|
| 13. |
XJAF-00202
|
[2] |
PIN-DOWEL
|
|
| 14. |
XJAF-00608
|
[2] |
PIN-DOWEL
|
|
| 15. |
XJAF-00609
|
[6] |
PIN-SPRING
|
|
| 16. |
XJAF-00610
|
[2] |
SEAL-SIDE
|
|
| 17. |
XJAF-00611
|
[1] |
BUSHING
|
|
| 18. |
XJAF-00612
|
[1] |
SHAFT-IDLER
|
|
| 19. |
XJAF-00613
|
[1] |
PLUG-TAPER
|
|
| 20. |
XJAF-00201
|
[7] |
PLUG-TAPERED
|
|
| 21. |
XJAF-00208
|
[1] |
PLUG-TAPER
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
