纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (874-60-1[1]) - HYD LINES, ARM 2. 13M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
740 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT43H00077F1 | [1] | Hyd Lines, Arm 2. 13m | |
| 1. | YT43H01104P1 | [2] | TUBE | KOB |
| 2. | YT43H01013D9 | [2] | HOSE ASSY. | KOBHose |
| 3. | YT43H01117P1 | [2] | BRACKET | KOB |
| 4. | 24100P1006F1 | [2] | VALVE | KOBAssy, Stop Superseded by part number: 24100P1006F2 |
| 4-1. | 2436P230 | [1] | VALVE BODY | KOB |
| 4-2. | 2436T304 | [1] | VALVE | KOB |
| 4-3. | 2418T8945D1 | [1] | SPACER | KOB |
| 4-4. | ZR16X04000 | [1] | RING | KOBSnap |
| 4-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBCap |
| 4-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 4-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 4-8. | ZD75G04000 | [1] | BACK-UP RING | KOB |
| 4-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 4-10. | ZD85G03500 | [1] | RING | KOBBack Up |
| 5. | ZA23F22012 | [2] | HYD CONNECTOR | KOB |
| 6. | ZD12P02400 | [2] | O-RING | KOB |
| 7. | YT43H01116P1 | [2] | CLAMP | KOB |
| 8. | ZS18C08025 | [8] | SCREW,Hex, M8 x 25mm | KOBCap |
| 9. | ZM73C10045 | [4] | BOLT,M10x45mm - Course Thread | KOBSems |
| 10. | YN43H01151P1 | [8] | WASHER | KOB |
| 11. | ZM73C12035 | [4] | BOLT,M12x35mm - Course Thread | KOBSems |
