| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | XJAF-01758 | [4] | PISTON | STD |
| 2. | XJAF-01759 | [4] | PISTON | 0.25MM O/S |
| 3. | XJAF-01760 | [4] | PISTON | 0.50MM O/S |
| 4. | XJAF-01114 | [4] | RING SET-PISTON | STD |
| N5. | @ | [4] | RING-NO 1 | |
| N6. | @ | [4] | RING-NO 2 | |
| N7. | @ | [4] | RING-OIL | |
| 8. | XJAF-01115 | [4] | RING SET-PISTON | 0.25MM O/S |
| 9. | XJAF-01116 | [4] | RING SET-PISTON | 0.50MM O/S |
| 10. | XJAF-01117 | [4] | PIN-PISTON | |
| 11. | XJAF-00653 | [8] | RING-SNAP | |
| N. | @ | [AR] | NOT SUPPLIED PARTS |
