| . . | 24100J15223F1 | [1] | NAME PLATE ASSY | NAME PLATE ASSY |
| 3. | 2432J2163 | [1] | NAME PLATE | NAME PLATE |
| 4. | 2432P2549 | [1] | LABEL | KOB |
| 5. | 2432J2162 | [2] | LABEL | KOB |
| 6. | 2432P2550 | [1] | LABEL | KOB |
| 7. | 2432P2551 | [1] | LABEL | KOB |
| 8. | 2432P2552 | [1] | LABEL | |
| 12. | 2432P2553 | [1] | LABEL | LABEL |
| 13. | 2432P2554 | [1] | LABEL | |
| 14. | 2432P2555 | [1] | LABEL | KOB |
| 15. | 2432P2556 | [1] | LABEL | KOB |
| 16. | 2432P2557 | [1] | LABEL | LABEL |
| 17. | 2432P2536D1 | [2] | LABEL | KOB |
| 19. | 2432T5342 | [1] | LABEL | KOB |
| 22. | 2432P2546D1 | [6] | LABEL | KOB |
| 25. | 2432P1734 | [1] | LABEL | KOBDecal, Warning - Operation of power boost … |
| 27. | 2427Z329D2 | [5] | SHEET | KOBAnti-Slip (400x150mm) |
| 28. | 2427Z329D3 | [2] | SHEET | KOBAnti-Slip (250x150mm) |
| 29. | 2418T10311 | [2] | PLATE | KOBØ30mm round Superseded by part number: 2418T27058 |
| 30. | 2432T4925 | [2] | LABEL | KOBØ40mm Transparent round |
| 32. | 2432T2283 | [1] | LABEL | KOBDecal, Fuel location |
| 33. | 2432T1231 | [1] | DATA PLAQUE | KOBDecal, Warning - |
| 34. | 2432T4781 | [1] | PLATE | KOB |
| 35. | 4020Z64 | [4] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 37. | 2432T5320 | [1] | LABEL | KOBDecal, Caution - Before stopping machine, idle it for five minutes. |
| 38. | 2432P2661 | [1] | DATA PLAQUE | KOBDecal, Caution - Exercise care when operating a bucket … |
| 39. | 2432P2633 | [1] | LABEL | KOBDecal, Filled with antifreeze This machine is filled with … |
| 40. | 2432T1215 | [1] | DATA PLAQUE | KOBDecal, Caution - To prevent accidents and bodily injury … |
| 41. | 2432T4962 | [1] | LABEL | KOBDecal, Lock Release |
| 42. | 2432N1097 | [2] | LABEL | KOBDecal, Danger - Stay out of the swing area. |
| 43. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, CAUTION (BREATHER PART) |
| 44. | 2432N2483 | [1] | LABEL | KOBSTD ARM HEAVY LIFT |
| 45. | 2432N2485 | [1] | LABEL | KOBLONG ARM HEAVY LIFT |
| 46. | 2432N2487 | [1] | LABEL | KOBSHORT ARM HEAVY LIFT |
| 47. | 2432N2635 | [1] | LABEL (LUBRICATION) | |
| 48. | 2432P2434 | [3] | LABEL | KOBDecal, Danger - Death or injury may result from … Superseded by part number: YN20T01006P1 |
| 50. | 2422T590 | [1] | REWORK, FRAME 4 - \u00d85.1 holes added | REWORK, FRAME 4 - Ø5.1 holes added |
| 51. | 2432P2579 | [1] | LABEL | KOB |
| 52. | 2432P2476 | [1] | LABEL | KOBDecal, Precautions - Avoid death or serious injury … |
| 53. | 2432T5321 | [1] | LABEL | KOBDecal, Caution - Pull out the connector when lifting … |
| 54. | 2432P2660 | [1] | LABEL | KOBDecal, Caution - Handle battery with caution … |
| 55. | 2432T5323 | [1] | LABEL | KOBDecal, Caution - To avoid serious personal injury, all … |
| 56. | 2432T5322 | [1] | LABEL | KOBDecal, Caution - Never open while coolant is hot. … |
| 57. | 2432P2508 | [1] | LABEL | KOBDecal, Warning - Operation of heavy lift … |
| 58. | 2432N2482 | [1] | LABEL | KOBSTD ARM |
| 59. | 2432N2484 | [1] | LABEL | KOBLONG ARM |
| 60. | 2432N2486 | [1] | LABEL | KOBSHORT ARM |
| 61. | 2432J1346 | [2] | LABEL | KOB |
| 62. | 2432T3920 | [1] | LABEL | KOB |
| 63. | 2432T3921 | [1] | LABEL | KOB |
| 64. | 2432T3922 | [1] | LABEL | KOB |
| 65. | 2432T3923 | [1] | LABEL | LABEL |
| 66. | 2432P2615 | [1] | LABEL | KOB |
| 67. | 2432P2616 | [1] | LABEL | KOB |
| 63. | 2432P2628 | [1] | LABEL | KOB |
| 69. | 2432P2629 | [1] | LABEL | KOB |
| 70. | 2432P2630 | [1] | LABEL | KOB |
| 71. | 2432P2664 | [1] | LABEL | |
| 72. | 2432T5271 | [1] | LABEL | KOB |
| 73. | 2432P2689 | [1] | LABEL | KOBDecal, Greasing Swing Bearing … |
