凯斯零件查询(3380) - PRECISION AIR CART (7/08-12/15) (00.100.06) - LAYOUT - DISPLAY MONITOR, SWITCH UNIT AND TRACTOR HARNESS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
712 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87668610
|
[1] |
DISPLAY
|
GI
field service black, Years: -01-AUG-08 Superseded by part number: 84604338R
|
| 1. |
87385125
|
[1] |
DISPLAY
|
GI
field service black, Start Year: 01-AUG-08 Superseded by part number: 84604338R
|
| 1. |
87385125R
|
[1] |
REMAN-ELECT MONITOR
|
RAC
Reman-Monitor 2280, 2380, 3380, 3480, Precision Air Carts Superseded by part number: 84604338R
|
| 1. |
87385125C
|
[1] |
CORE-MONITOR
|
RAC
Return Part Number
|
| 1. |
84604338R
|
[1] |
REMAN-ELECT MONITOR
|
GI
2330, 2280 Both(1/08), 3380, 3430 Both(7/08), Reman For 87385125
|
| 1. |
84604338C
|
[1] |
CORE-MONITOR
|
GI
Return Part Number
|
| 2. |
87703363
|
[1] |
CONTROL MONITOR
|
ZED
small wide configurable, Years: -01-FEB-10
|
| 2. |
87703363R
|
[1] |
REMAN-ELECT MONITOR
|
ZED
2280, 2330 BOTH (1/08-), 3380, 3430 BOTH (7/08-)
|
| 2. |
87703363C
|
[1] |
CORE-MONITOR
|
ZED
Return Part Number
|
| 2. |
84240403
|
[1] |
CONTROL MONITOR
|
BAS
Small Wide Configurable Display 1.5TS-CIH, Start Year: 01-FEB-10 Superseded by part number: 47585553
|
| 2. |
84486874R
|
[1] |
REMAN-ELECT MONITOR
|
ZED
2280, 2330, Both (1/08-), 3380, 3430, Both (7/08-), Reman for New PN 84240403 Superseded by part number: 47585553R
|
| 2. |
84486874C
|
[1] |
CORE-MONITOR
|
ZED
Return Part Number
|
| 3. |
87588879
|
[1] |
SWITCH
|
SAS
unit, auxiliary
|
| 4. |
87532170
|
[1] |
HARNESS
|
SAS
tractor 7.6 m
|
| 5. |
87601142
|
[1] |
ELEC CONNECTOR,Female, 6 Cavities
|
PLO
electronic control unit
|
| 6. |
GL-521
|
[1] |
MOUNTING PARTS
|
FLX
implement receptacle
|
| 7. |
14294
|
[1] |
HARNESS
|
FLX
power adapter, Years: -01-APR-10 Superseded by part number: 84261537
|
| 7. |
84261537
|
[1] |
HARNESS
|
SAS
power adapter, Start Year: 01-APR-10
|
| 8. |
1983420C2
|
[1] |
RELAY
|
IH
12v 85 ohm c/w bracket
|
