纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (033-01[1]) - RADIATOR GROUP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
496 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT05P00018F1 | [1] | Radiator Group | |
| 1. | YT05P01243F1 | [1] | GUARD | KOBAssy |
| 1-1. | YT05P01244P2 | [1] | GUARD | KOBGuard |
| 1-2. | YT05P01084P1 | [1] | RUBBER SEAL | KOB |
| 1-3. | YT05P01085P1 | [1] | RUBBER SEAL | KOB |
| 1-4. | YT05P01151P1 | [1] | RUBBER SEAL | KOB |
| 1-5. | YN21C01692D2 | [1] | TRIM PANEL | KOB Superseded by part number: YN21C01692D8 |
| 2. | YT50V01015P1 | [1] | FILTER | KOB |
| 3. | YT05P01247F1 | [1] | BRACKET | KOBAssy |
| 3-1. | YT05P01248P2 | [1] | BRACKET | KOBBracket |
| 3-2. | YT05P01163P1 | [1] | RUBBER SEAL | KOB |
| 3-3. | YT05P01164P1 | [1] | RUBBER SEAL | KOB |
| 4. | YT05P01093F1 | [1] | PLATE | KOBPlate Assy |
| 4-1. | YT05P01094P1 | [1] | PLATE | KOBPlate |
| 4-2. | PM21C01152D4 | [1] | WEATHERSTRIP | KOB |
| 5. | YT05P01227P1 | [1] | GUARD | KOB |
| 6. | YT05P01041F1 | [1] | TANK | KOBAssy, Water, Sub |
| 8. | YT05P01203P1 | [1] | BRACKET | KOBBracket |
| 9. | YT05P01257P1 | [1] | BRACKET | KOBBracket |
| 10. | 2416Z519 | [1] | U-BRACKET | KOB |
| 11. | YT05P01065P1 | [1] | RADIATOR HOSE | KOB |
| 12. | YT05P01239P1 | [1] | RADIATOR HOSE | KOB |
| 13. | YT05P01180P1 | [1] | FLEXIBLE HOSE | KOB |
| 14. | YT05P01181P1 | [1] | FLEXIBLE HOSE | KOB |
| 15. | YT05P01069P1 | [1] | FLEXIBLE HOSE | KOB |
| 16. | YT05P01182P1 | [1] | TUBE | KOB |
| 17. | NSS | [1] | NOT SERVICED SEPARATELY | CONHose (with Radiator) |
| 18. | 2427P1836D14 | [1] | WEATHERSTRIP | KOB |
| 19. | 2420T2948D20 | [1] | U-BOLT | KOB |
| 21. | ZC46X50014 | [1] | CLIP | KOB |
| 22. | ZC16X04200 | [3] | CLAMP | KOB |
| 23. | ZC16X05100 | [2] | CLIP | KOB |
| 24. | ZC16X05800 | [5] | CLIP | KOB |
| 25. | ZM73C10025 | [3] | BOLT,M10x25mm - Course Thread | KOBSems |
| 28. | ZM73C08020 | [12] | BOLT,M8x20mm - Course Thread | KOBSems |
| 29. | ZM73C08016 | [10] | BOLT,M8x16mm - Course Thread | KOBSems |
| 30. | ZM61C06020 | [2] | BOLT | KOBSems |
| 31. | ZN18C08007 | [4] | NUT | KOB |
| 32. | ZW16P08000 | [2] | WASHER | KOB |
| 33. | YT05P01225F2 | [1] | COVER ASSY | KOB |
| 33-1. | YT05P01223P1 | [1] | PLATE | KOBPlate |
| 33-2. | YT05P01226P1 | [1] | RUBBER SEAL | KOB |
| 33-3. | YT05P01264P1 | [1] | RUBBER SEAL | KOB |
| 34. | YT05P01266P1 | [1] | GASKET | KOBPacking, Start Serial: LF05-04260 |
