凯斯零件查询(3380) - PRECISION AIR CART (7/08-12/15) (35.110.01) - HYDRAULICS - MAIN FRAME - VARIABLE DRIVE (3 TANK) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
261 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
128996
|
[5] |
TEE,3/4" - 16 JIC x 3/4" - 16 JIC x 3/4" - 16 JIC
|
WIN
|
| 2. |
22519
|
[1] |
LINE
|
FLX
hydraulic 1/2" od x 30 1/2" ~ 1/2" fjic x 1/2" fjic
|
| 4. |
22518
|
[1] |
LINE
|
FLX
hydraulic 1/2" od x 28 1/2" ~ 1/2" fjic x 1/2" fjic
|
| 5. |
87446695
|
[3] |
HYDRAULIC HOSE
|
SAS
3/8" x 23" fl, 1/2" fjic x 3/8" fjic
|
| 6. |
87446398
|
[3] |
HYDRAULIC HOSE,0.38" ID x 20.00", SAE J517, SAE J516, SAE J343
|
SAS
1/2" fjic x 3/8" fjic
|
| 7. |
22517
|
[4] |
LINE
|
FLX
hydraulic 1/2" od x 31" ~ 1/2" fjic x 1/2" fjic
|
| 8. |
87500080
|
[1] |
HYDRAULIC HOSE
|
SAS
1/2" x 45" fl
|
| 9. |
87504025
|
[1] |
FILTER
|
SAS
hyd in-line 8forb 25 m
|
| 10. |
22447
|
[3] |
VALVE
|
FLX
1 1/4" gpm p. comp deltrol pressure compensated
|
| 11. |
76350
|
[6] |
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
|
NH
|
| 12. |
GM-363
|
[3] |
HYDRAULIC MOTOR
|
FLX
torque generator 2 3/16" 3/rev Superseded by part number: 22709
|
| 13. |
22448
|
[3] |
FITTING
|
FLX
hydraulic - straight adapter 3/8" morb x 3/8" morb
|
| 14. |
128818
|
[1] |
UNION,3/4" - 16 ORB x 3/4" - 16 JIC
|
BHB
|
| 15. |
412756A1
|
[1] |
FITTING
|
FLX
1/2" mb 1/2" fjx Superseded by part number: 87698808
|
| 16. |
216791
|
[1] |
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree
|
PA
|
| 18. |
84307616
|
[1] |
CLAMP
|
SAS
plastic, hydraulic tube
|
| 19. |
88436
|
[2] |
BOLT,Hex, 3/8" - 16 x 2", Gr 5
|
GI
|
| 20. |
80664
|
[2] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 21. |
88902
|
[2] |
NUT,3/8"-16
|
NH
|
| 22. |
87504039
|
[1] |
SERVICE KIT
|
SAS
filter oil element & seal
|
| 24. |
22396
|
[1] |
SEAL KIT
|
FLX
torque generator
|
