纽荷兰零件查询(65B) - MOTORGRADERS (A1.01[003]) - CYLINDER HEAD (8061.05 ENGINE) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
887 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4699155 | [6] | CONVEYOR | MODDEFLECTOR Superseded by part number: 4808105 |
| 2. | 4770859 | [6] | SLEEVE | TORNOZZLE HOLDER |
| 3. | 4796457 | [26] | BOLT,Flng, M12 x 1.25 x 122.5mm | TORCAPSCREW |
| 4. | 4782867 | [1] | CYLINDER HEAD | MODHEAD, CYLINDER Superseded by part number: 4832022, 16100821, 4817998, 14048211 |
| 6. | 4754068 | [1] | CYLINDER HEAD GASKET | MODGASKET Superseded by part number: 4754069 |
| 8. | 10305171 | [1] | PLUG,M22 x 1.5 x 21 | TTF Superseded by part number: 16992611 |
| 9. | 10263460 | [1] | SEAL,22.3mm ID x 28mm OD x 1.5mm Thk | TTFWASHER, SEALING, M22.3 x 28 x 1.5 Superseded by part number: 16508460 |
| 10. | 13517530 | [12] | STUD,M8 x 1.25 x 45mm | TOR Superseded by part number: 500380521 |
| 12. | 14453981 | [12] | O-RING,0.989" ID x 0.07" Width | TTF-022, Cl 7, .989 " ID x .070" Thk |
| 13. | 14282770 | [1] | PLUG,M36, Tapered, Stainless | TOR Superseded by part number: 16991170 |
| 14. | 14282170 | [1] | PLUG,M20, Tapered, Stainless | TOR20 |
| 15. | 14282470 | [12] | PLUG,M28, Tapered, Stainless | TOR28 Superseded by part number: 16990870 |
| 16. | 14282970 | [1] | PLUG,M45, Tapered, Stainless | TOR45 Superseded by part number: 16991370 |
| 17. | 14323911 | [1] | PLUG | TTF |
