纽荷兰零件查询(65B) - MOTORGRADERS (A1.01[005]) - LIFTING EYES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1030 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4695923 | [1] | EYELET | MODEYE,REAR, RIGHT |
| 2. | 4695922 | [1] | EYELET | MODEYE,REAR, LEFT |
| 3. | 4746561 | [1] | EYELET | MODEYE, FRONT |
| 4. | 11193871 | [1] | BELLEVILLE WASHER,Belleville, M8.4 | TTFLOCKWASHER Superseded by part number: 11193874 |
| 5. | 11198071 | [2] | BELLEVILLE WASHER,Belleville, M8.4 | TORWASHER, SPRING, Belleville, M8.4 Superseded by part number: |
| 6. | 11198371 | [1] | BELLEVILLE WASHER,Belleville, M10.5 | MKTLOCKWASHER Superseded by part number: 11198374 |
| 7. | 15970521 | [1] | BOLT,Hex, M10 x 1.25 x 20mm, Cl 8.8, Full Thd | TTFBOLT, Hex, M10 x 1.25 x 20, 8.8, Full Thd Superseded by part number: 15970524 |
| 8. | 16100811 | [1] | NUT,Hex, M8, 6.80mm, Cl 8, ZND | TTFM8, Cl 8 Superseded by part number: 43362 |
| 9. | 16043221 | [2] | BOLT,Hex, M8 x 16mm, Cl 8.8, Full Thd | HFIBOLT, Hex, M8 x 16, 8.8 Superseded by part number: 16043224 |
