| 2. |
21555
|
[2] |
HYDRAULIC HOSE,25.4mm ID x 12319mm L, SAE 100R17
|
FLX
1" x 485" fl, 3/4" mpt x 1" mpt Superseded by part number: 47640673
|
| 3. |
GL-700.32
|
[2] |
DECAL
|
FLX
fan pressure
|
| 4. |
87501182
|
[4] |
COVER
|
SAS
hose label, 1 1/2"
|
| 5. |
9412
|
[4] |
QUICK MALE COUPLING
|
FLX
1/2" Superseded by part number: 9801618
|
| 6. |
21668
|
[2] |
REDUCER FITTING,1/2" - 14 Male NPT x 3/4" - 14 Female NPT
|
FLX
hydraulic 1/2" mpt x 3/4" fpt
|
| 7. |
9360
|
[2] |
PLUG
|
FLX
dust, pioneer coupler - 1"
|
| 8. |
9359
|
[2] |
COUPLING, QUICK, FEM
|
FLX
1"
|
| 9. |
GL-700.33
|
[2] |
DECAL
|
FLX
fan return
|
| 10. |
87500095
|
[1] |
HYDRAULIC HOSE,19mm ID x 12319mm L
|
SAS
3/4" x 485" fl, 1/2" mpt x 1/2" mpt Superseded by part number: 47661973
|
| 11. |
GL-700.42
|
[2] |
DECAL
|
FLX
drain
|
| 13. |
1994568C1
|
[1] |
COUPLING, QUICK, FEM
|
CAS
1/2" fpt
|
| 14. |
86592083
|
[1] |
DUST CAP
|
ZED
pioneer coupler - 1/2"
|
| 15. |
85999239
|
[1] |
QUICK MALE COUPLING,3/8" x 3/4" - 16 ORB
|
PA
stl 3/8"
|
| 16. |
218-5254
|
[1] |
HYD CONNECTOR,3/4" - 16 ORB x 1/2" - 14 NPT
|
CAS
|
| 17. |
GL-508
|
[1] |
CLAMP
|
FLX
plate
|
| 18. |
425021A1
|
[2] |
CLAMP
|
FLX
clamp, 2" complete
|
| 19. |
88902
|
[5] |
NUT,3/8"-16
|
NH
|
| 20. |
GH-601
|
[1] |
COUPLING
|
FLX
hydraulic mount third line
|
| 21. |
1569
|
[1] |
U-BOLT
|
FLX
ur 5/16" x 1 3/8" w x 2 1/16" d 3/4" thread
|
| 22. |
280736
|
[4] |
NUT,5/16"-18, GC
|
NH
|
| 23. |
88206
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 24. |
GE-202
|
[1] |
CLAMP
|
FLX
for two 3/4" couplers
|
| 25. |
3236
|
[2] |
SELF-TAP SCREW
|
FLX
1/4"-20 x 1 1/4" oh pi plt
|
| 26. |
280129
|
[2] |
NUT,1/4"-20
|
NH
|
| 27. |
87657
|
[2] |
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 5
|
NH
|
| 28. |
9706729
|
[1] |
BOLT,Hex, 7/16" - 14 x 1", Gr 5, Full Thd
|
NH
|
| 29. |
280980
|
[1] |
NUT,7/16"-14, GC
|
NH
|
| 30. |
21560
|
[2] |
HYDRAULIC HOSE,19.05mm ID x 12319mm L, SAE 100R17
|
FLX
3/4" x 485" fl, 1/2" mpt x 3/4" mpt Superseded by part number: 47692418
|
| 31. |
GL-700.34
|
[2] |
DECAL
|
FLX
auger pressure
|
| 32. |
GL-373
|
[4] |
COVER
|
FLX
hydraulic hose label - 1 1/2"
|
| 33. |
6934
|
[2] |
PLUG
|
FLX
dust, pioneer coupler - 3/4"
|
| 34. |
6935
|
[2] |
COUPLING, QUICK, FEM
|
FLX
3/4"
|
| 35. |
GL-700.35
|
[2] |
DECAL
|
FLX
auger return
|
| 36. |
GL-509
|
[1] |
BRACKET
|
FLX
|
