凯斯零件查询(3380) - PRECISION AIR CART (7/08-12/15) (35.910.AB[01]) - DELUXE AUGER MOTOR ASSEMBLY AND MOUNTING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
907 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47432133
|
[1] |
STOP
|
SAS
Cylinder Red
|
| 2. |
47434211
|
[1] |
CONTROL VALVE
|
SAS
Auger
|
| 3. |
47384016
|
[1] |
CHUTE
|
SAS
10 Inch Auger Tube
|
| 4. |
84583852
|
[1] |
HYDRAULIC MOTOR
|
SAS
Eaton 2000 Superseded by part number: 47857782
|
| 5. |
84384047
|
[1] |
AUGER FLIGHT
|
SAS
10 Inch
|
| 6. |
GL-657
|
[2] |
RETAINER
|
FLX
Auger Tube
|
| 7. |
84300017
|
[1] |
ADHESIVE STRIP
|
SAS
Anti Slip 638MM
|
| 8. |
84300016
|
[1] |
HOSE,890.00 mm
|
SAS
Auger Discharge
|
| 9. |
84583850
|
[1] |
HYDRAULIC VALVE
|
SAS
|
| 10. |
84589126
|
[1] |
CONTROL
|
SAS
Auger Valve Lower
|
| 11. |
23781
|
[2] |
GRIP
|
FLX
Handle Yellow Superseded by part number: 51200111, 51200111, NLS
|
| 12. |
280561
|
[1] |
BOLT,Hex, 1/2" - 20 x 2 3/4", Gr 8
|
GI
|
| 13. |
87333768
|
[1] |
NUT,1/2" - 20
|
GI
1/2
|
| 14. |
9707516
|
[4] |
BOLT,1/2"-13 x 1-3/4", Cl 5
|
WIN
|
| 15. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 16. |
280431
|
[4] |
NUT,1/2"-13, G5
|
NH
|
| 17. |
88011
|
[4] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
NH
|
| 18. |
9637692
|
[4] |
NUT,3/8"-16, GB
|
NH
|
| 19. |
76088794
|
[2] |
HOSE CLAMP,8.12" - 9"
|
LEC
#136 Superseded by part number: 214-14136
|
| 20. |
87574044
|
[2] |
PIN
|
SAS
Square Wire Hook
|
| 21. |
88434
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
NH
|
| 22. |
80664
|
[2] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 23. |
6248
|
[1] |
LOCK PIN,5/16" x 1 1/2", Slotted
|
FLX
Roll Superseded by part number: 438-12024
|
| 24. |
8559
|
[1] |
PIN,5/16" x 3"
|
FLX
Roll
|
| 25. |
86983984
|
[3] |
CLAMP
|
SAS
Hose
|
| 26. |
88436
|
[2] |
BOLT,Hex, 3/8" - 16 x 2", Gr 5
|
GI
|
| 27. |
88044
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
|
NH
|
| 28. |
88902
|
[3] |
NUT,3/8"-16
|
NH
|
| 29. |
47430062
|
[1] |
SEAL KIT
|
SAS
Dlx Auger
|
