纽荷兰零件查询(65B) - MOTORGRADERS (A1.07[002]) - ROCKER ARMS & SUPPORTS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
154 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4846851 | [1] | SCREW,M6 x 25mm | TOR |
| 2. | 4570798 | [4] | WASHER | TORMASHER , +0.7 |
| 3. | 4570799 | [4] | WASHER | TORWASHER, +0.5 |
| 4. | 4683070 | [1] | SHAFT | MOD Superseded by part number: 4838844 |
| 5. | 4681251 | [12] | ROCKER ARM | FORROCKER Superseded by part number: 4848973 |
| 6. | 4601295 | [6] | SUPPORT | TOR |
| 7. | 4682937 | [12] | BUSHING,17.82mm ID x 21.03mm OD x 22.8mm L | TOR |
| 8. | 4639661 | [10] | THRUST WASHER,18mm ID x 24mm OD x 1mm | TOR |
| 9. | 4601296 | [3] | SPRING | TOR |
| 10. | 11066675 | [2] | LOCKING RING | MKTLOCKRING Superseded by part number: 11066676 |
| 11. | 11198071 | [12] | BELLEVILLE WASHER,Belleville, M8.4 | TORWASHER, SPRING, Belleville, M8.4 Superseded by part number: |
| 12. | 13516621 | [6] | STUD | MKT Superseded by part number: 16729224 |
| 13. | 14328301 | [2] | PLUG,M12, Tapered | TOR |
| 14. | 16044521 | [6] | SCREW,Hex, M8 x 65mm, Cl 8.8 | FORCAP SCREW, M8 X 65 Superseded by part number: 16606424 |
| 15. | 16100811 | [6] | NUT,Hex, M8, 6.80mm, Cl 8, ZND | TTFM8, Cl 8 Superseded by part number: 43362 |
