现代零件查询R75-7 CONTROL VALVE 1EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
227 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01970
|
[1] |
CONTROL VALVE ASSY
|
|
| 2. |
XJDH-02259
|
[1] |
SPRING
|
|
| 3. |
XJDH-02260
|
[1] |
SPRING
|
|
| 4. |
XJDH-00115
|
[22] |
BOLT-SOCKET HEAD
|
|
| 5. |
XJDH-02261
|
[2] |
CAP
|
|
| 6. |
XJDH-02262
|
[1] |
CAP
|
|
| 7. |
XJDH-00328
|
[1] |
O-RING
|
|
| 8. |
XJDH-02263
|
[9] |
COVER
|
|
| 9. |
XJDH-02264
|
[9] |
CAP-PL
|
|
| 10. |
XJDH-02265
|
[9] |
O-RING
|
|
| 11. |
XJDH-02266
|
[9] |
O-RING
|
|
| 12. |
XJDH-02267
|
[2] |
O-RING
|
|
| 13. |
XJDH-02268
|
[1] |
GUIDE-SPRING
|
|
| 14. |
XJDH-02269
|
[1] |
CAP-PL
|
|
| 15. |
XJDH-02270
|
[1] |
SPACER
|
|
| 16. |
XJDH-02271
|
[2] |
COVER
|
|
| 17. |
XJDH-02272
|
[1] |
NUT
|
|
| 18. |
XJDH-02273
|
[1] |
SPACER
|
|
| 19. |
XJDH-02274
|
[1] |
SPACER
|
|
| 20. |
XJDH-02275
|
[1] |
CAP-PL
|
|
| 21. |
XJDH-02276
|
[1] |
GUIDE-SPRING
|
|
| 22. |
XJDH-02277
|
[1] |
O-RING
|
|
| 23. |
XJDH-02278
|
[9] |
SPRING
|
|
| 24. |
XJDH-02279
|
[9] |
CHECK
|
|
| 25. |
XJDH-02280
|
[1] |
MAIN RELIEF ASSY(P3)
|
|
| 26. |
XJDH-00331
|
[6] |
O-RING
|
|
| 27. |
XJDH-02281
|
[4] |
RING-BACK UP
|
|
| 28. |
XJDH-00326
|
[4] |
O-RING
|
|
| 29. |
XJDH-02282
|
[2] |
PORT RELIEF ASSY
|
|
| 30. |
XJDH-02283
|
[1] |
CAP
|
|
| 31. |
XJDH-02284
|
[1] |
PLUG
|
|
| 32. |
XJDH-02285
|
[3] |
CAP
|
|
| 33. |
XJDH-00334
|
[3] |
O-RING
|
|
| 34. |
@
|
[2] |
PLUNGER-M1
|
|
| 35. |
@
|
[1] |
PLUNGER-C2
|
|
| 36. |
@
|
[1] |
PLUNGER-S9
|
|
| 37. |
@
|
[1] |
PLUNGER-S2
|
|
| 38. |
@
|
[1] |
SPOOL
|
|
| 39. |
@
|
[1] |
PLUNGER-B1
|
|
| 40. |
@
|
[1] |
PLUNGER-C1
|
|
| 41. |
@
|
[1] |
SPOOL
|
|
| 42. |
@
|
[1] |
PLUNGER-D9
|
|
| 43. |
@
|
[1] |
PLUNGER-D3
|
|
| 44. |
XJDH-01738
|
[1] |
PORT RELIEF ASSY
|
|
