| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
6662147100
|
[2] |
LABEL KUBOTA
|
0.0022(lbs); 0.001
|
| 020. |
6642747120
|
[1] |
LABEL HI-LO SHIFT
|
0.0022(lbs); 0.001
|
| 030. |
6620447133
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 040. |
6642647140
|
[1] |
LABEL LIFT
|
0.0044(lbs); 0.002
|
| 050. |
6642647150
|
[1] |
LABEL 4WD
|
0.0110(lbs); 0.005
|
| 060. |
6620447180
|
[2] |
LABEL B7100HST
|
0.0044(lbs); 0.002
|
| 070. |
6659147190
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 080. |
6620447190
|
[1] |
LABEL OIL FILLER
|
0.0022(lbs); 0.001
|
| 090. |
6620447213
|
[1] |
LABEL OIL
|
0.0022(lbs); 0.001
|
| 100. |
6620447220
|
[2] |
LABEL OIL
|
0.0022(lbs); 0.001
|
| 110. |
6620447230
|
[1] |
LABEL RELEASE
|
0.0022(lbs); 0.001
|
| 120. |
6670647240
|
[1] |
LABEL GLOW PLUG
|
0.0022(lbs); 0.001
|
| 130. |
6670647250
|
[1] |
NAME PLATE SPACER
|
0.0022(lbs); 0.001
|
| 140. |
6670647260
|
[1] |
MARK TOOLS CASE
|
0.0022(lbs); 0.001
|
| 150. |
K331147340
|
[1] |
MARK KUBOTA
|
0.0088(lbs); 0.004
|
| 190. |
3526034913
|
[1] |
LABEL SAFETY
|
0.0110(lbs); 0.005
|
| 190. |
3526134910
|
[1] |
LABEL SAFETY
|
0.0132(lbs); 0.006
|
| 200. |
3582098632
|
[1] |
LABEL START CAUTION
|
0.0066(lbs); 0.003
|
| 210. |
6706147240
|
[1] |
LABEL SPEED LOCK
|
0.0022(lbs); 0.001
|
| 210. |
3253065930
|
[1] |
LABEL START CAUTION
|
0.0022(lbs); 0.001
|
| 220. |
6620447420
|
[1] |
LABEL PANEL
|
0.0000(lbs); 0.000
|
| 230. |
6620447410
|
[1] |
LABEL PANEL
|
0.0440(lbs); 0.020
|
| 240. |
6670447440
|
[1] |
LABEL KUBOTA
|
0.0022(lbs); 0.001
|
| 250. |
3511032420
|
[1] |
PLUG
|
0.0044(lbs); 0.002
|
| 260. |
6670647340
|
[1] |
LABEL CAUTION
|
0.0022(lbs); 0.001
|
| 270. |
6642747350
|
[1] |
LABEL DIFF.LOCK
|
0.0022(lbs); 0.001
|
| 270. |
7661147520
|
[1] |
LABEL DIFF.LOCK
|
0.0022(lbs); 0.001
|
| 280. |
6620447360
|
[1] |
LABEL PARKING BRAKE
|
0.0022(lbs); 0.001
|
| 290. |
6620447370
|
[1] |
LABEL BRAKE LOCK
|
0.0044(lbs); 0.002
|
| 310. |
6670647420
|
[1] |
LABEL FUEL TANK
|
0.0022(lbs); 0.001
|
| 320. |
3526029790
|
[1] |
LABEL DRAWBAR
|
0.0044(lbs); 0.002
|
| 320. |
3587198660
|
[1] |
LABEL DRAWBAR
|
0.0022(lbs); 0.001
|
| 330. |
3511021990
|
[1] |
LABEL ONE WAY CLUTCH
|
0.0022(lbs); 0.001
|
| 340. |
3520025340
|
[1] |
LABEL PTO WARNING
|
0.0044(lbs); 0.002
|
| 340. |
6784047210
|
[1] |
LABEL PTO
|
0.0022(lbs); 0.001
|
| 350. |
3526029782
|
[1] |
LABEL ROPS WARNING
|
0.0022(lbs); 0.001
|
| 350. |
3587198640
|
[1] |
LABEL ROPS WARNING
|
0.0044(lbs); 0.002
|
| 360. |
6620447464
|
[1] |
NAME PLATE
|
0.0220(lbs); 0.010
|
| 370. |
5410224410
|
[4] |
RIVET
|
0.0022(lbs); 0.001
|
| 380. |
6620447510
|
[1] |
NAME PLATE
|
0.0990(lbs); 0.045
|
| 390. |
0300450610
|
[4] |
SCREW WITH WASHER
|
0.0088(lbs); 0.004
|
| 400. |
6642747520
|
[1] |
LABEL MAIN SHIFT
|
0.0110(lbs); 0.005
|
| 410. |
6642747530
|
[1] |
LABEL FORWARD
|
0.0022(lbs); 0.001
|
| 420. |
6642747540
|
[1] |
LABEL REVERSE
|
0.0110(lbs); 0.005
|
| 430. |
6620447550
|
[2] |
MARK 4-WHEEL DRIVE
|
0.0066(lbs); 0.003
|
