神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (17-054) - FUEL FEED PUMP (INNER PARTS) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
240 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-36. | VAME717104 | [1] | PUMP | KOBFUEL FEED ASSY M5 ONLY ZXL 1052104700 |
| . . | VAME730303 | [1] | FEED PUMP | KOBFUEL ASSY M6 ONLY ZXL 1052105250 |
| 1. | VAME716556 | [1] | HOUSING, FEED PUMP ZXL 1520510620 | |
| 5. | VAME705020 | [1] | PISTON | KOBZXL 1521001120 Superseded by part number: VA1521001120 |
| 6. | VAME705021 | [1] | SPRING | KOBPISTON ZXL 1521020400 |
| 7. | VAME705022 | [1] | PLUG | KOBZXL 1521050200 |
| 8. | VAME705275 | [1] | GASKET | KOBZXL 0293326030 Superseded by part number: VA0293326030 |
| 10. | VAME705099 | [1] | TAPPET | KOBZXL 1521112820 |
| 14. | VAME726483 | [2] | CHECK VALVE | KOBZXL 1521150500, Start Serial: 8907- Superseded by part number: VA1521150200 |
| . . | VAME705027 | [2] | VALVE | KOBZXL 1521150200, Serial Range: --8906 Superseded by part number: VA1521150200, 77270043 |
| 15. | VAME705028 | [2] | SPRING | KOBCHECK/V ZXL 1521160200 Superseded by part number: 77270044, VA1521160200 |
| 16. | VAME705029 | [1] | PLUG | KOBZXL 1521170100 |
| 18. | VAME705276 | [2] | PACKING | KOBGASKET ZXL 0293316030 Superseded by part number: VA0293316030, 77270063 |
| 20. | VAME705030 | [1] | RING | KOBSNAP ZXL 1521210200 |
| 25. | VAME717630 | [1] | LUBE PUMP | KOBPUMP, PRIMING ZXL 1522005620 Superseded by part number: VA1522005620 |
| 30. | VAME717659 | [1] | BOLT | KOBEYE ZXL 1523006920 Superseded by part number: VA1523006920 |
| 32. | VAME717882 | [1] | BOLT | KOBEYE M5 ONLY ZXL 1398140900 Superseded by part number: VA1398140900 |
| . . | NSS | [1] | NOT SOLD SEPARAT | CONM6 ONLY ZXL |
| 35. | VA3126106400 | [2] | GASKET | KOBZXL 0293414130 Superseded by part number: VA0293414130 |
| 36. | VA3126106400 | [2] | GASKET | KOBZXL 0293414130 Superseded by part number: VA0293414130 |
