现代零件查询R75-7 WORK EQUIPMENT PIPING 1EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
616 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-00457
|
[2] |
CONNECTOR-MALE
|
|
| 2. |
XJDH-00457
|
[2] |
CONNECTOR-MALE
|
|
| 3. |
XJDH-00457
|
[2] |
CONNECTOR-MALE
|
|
| 4. |
XJDH-00457
|
[5] |
CONNECTOR-MALE
|
|
| 5. |
XJDH-00459
|
[2] |
CONNECTOR-MALE
|
|
| 6. |
XJDH-00456
|
[1] |
CONNECTOR-MALE LONG
|
|
| 7. |
XJDH-00334
|
[12] |
O-RING
|
|
| 8. |
XJDH-00336
|
[2] |
O-RING
|
|
| 9. |
XJDH-01730
|
[1] |
CONNECTOR
|
|
| 10. |
XJDH-00334
|
[1] |
O-RING
|
|
| 11. |
XJDH-00414
|
[1] |
VALVE-CHECK
|
|
| 12. |
XJDH-00438
|
[1] |
TEE
|
|
| 13. |
XJDH-00390
|
[1] |
PLUG/O-RING BOSS
|
|
| 14. |
XJDH-00336
|
[1] |
O-RING
|
|
| 15. |
XJDH-00692
|
[3] |
HOSE(G,I,J)
|
|
| 16. |
XJDH-00691
|
[1] |
HOSE(H)
|
|
| 17. |
XJDH-00694
|
[1] |
HOSE(O)
|
|
| 18. |
XJDH-00690
|
[1] |
HOSE(P)
|
|
| 19. |
XJDH-00693
|
[2] |
HOSE(Q,R)
|
|
| 20. |
XJDH-00666
|
[1] |
HOSE(U)
|
|
| 21. |
XJDH-00681
|
[1] |
HOSE(X)
|
|
| 22. |
XJDH-01724
|
[1] |
PIPE(D)
|
|
| 23. |
XJDH-01725
|
[1] |
PIPE(E)
|
|
| 24. |
XJDH-01726
|
[2] |
PIPE(F)
|
|
| 25. |
XJDH-01243
|
[5] |
CLAMP-PIPE(B)
|
|
| 26. |
XJDH-00073
|
[5] |
BOLT
|
|
| 27. |
XJDH-00280
|
[5] |
WASHER
|
|
| 28. |
XJDH-01720
|
[4] |
PLATE-TIGHTEN
|
|
| 29. |
XJDH-00054
|
[4] |
BOLT
|
|
| 30. |
XJDH-00165
|
[4] |
NUT
|
|
| 31. |
XJDH-00276
|
[8] |
WASHER
|
|
| 32. |
XJDH-00614
|
[2] |
HOSE(AO,AP)
|
|
| 33. |
XJDH-00613
|
[2] |
HOSE
|
|
| 34. |
XJDH-01643
|
[1] |
COVER
|
|
| 35. |
XJDH-01644
|
[2] |
PLATE-RUBBER
|
|
| 36. |
XJDH-00057
|
[2] |
BOLT
|
|
| 37. |
XJDH-00278
|
[2] |
WASHER
|
|
| 38. |
XJDH-01645
|
[2] |
RUBBER
|
|
| 39. |
XJDH-01714
|
[1] |
PLATE-GUIDE
|
|
| 40. |
XJDH-00057
|
[2] |
BOLT
|
|
| 41. |
XJDH-00278
|
[2] |
WASHER
|
|
