凯斯零件查询(4955) - PRECISION AIR CART (11/15-) (77.100.XX[21]) - CONVEYOR HEAD Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
695 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47879303
|
[1] |
TUBE
|
SAS
SHAFT GUARD, 1"-1-1/4"
|
| 2. |
47753220
|
[1] |
COVER
|
SAS
BEARING COVER, 1-1/4" , MOLDED
|
| 3. |
47686591
|
[2] |
FLANGE
|
SAS
FLANGE BLOCK 1 1/4" SHAFT BEARING 8" CONVE
|
| 4. |
47686592
|
[1] |
DRUM
|
SAS
DRIVE ROLLER, 5"
|
| 5. |
47879308
|
[1] |
CLAMP
|
SAS
RIGID CLAMP COUPLER, 1" DIA. TO 1-1/4" DIA., STEEL
|
| 6. |
47686594
|
[1] |
MOTOR-PUMP
|
SAS
HYD. MOTOR, 8.0 CU IN, 1" SHAFT
|
| 7. |
47686601
|
[1] |
SPOUT
|
SAS
MOLDED
|
| 8. |
47686602
|
[1] |
HOUSING
|
SAS
UPPER HOUSING ASSEMBLY
|
| 9. |
47686611
|
[1] |
COVER
|
SAS
COVER, TOP
|
| 10. |
47686612
|
[1] |
COVER
|
SAS
COVER, BOTTOM
|
| 11. |
47686613
|
[1] |
BRACKET
|
SAS
UPPER BEARING - LH
|
| 12. |
47686616
|
[1] |
BRACKET
|
SAS
UPPER BEARING - RH
|
| 13. |
47879313
|
[1] |
ARM
|
SAS
TORQUE ARM
|
| 14. |
47686620
|
[2] |
PLATE
|
SAS
CONNECTOR
|
