现代零件查询R75-7 UPPER FRAME PIPING 4EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
947 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-00467
|
[3] |
ELBOW-MALE 90
|
|
| 2. |
XJDH-00462
|
[2] |
ELBOW-MALE 45
|
|
| 3. |
XJDH-00386
|
[2] |
PLUG
|
|
| 4. |
XJDH-00467
|
[1] |
ELBOW-MALE 90
|
|
| 5. |
XJDH-00445
|
[1] |
CONNECTOR-MALE
|
|
| 6. |
XJDH-00328
|
[11] |
O-RING
|
|
| 7. |
XJDH-00460
|
[1] |
CONNECTOR-MALE
|
|
| 8. |
XJDH-00336
|
[1] |
O-RING
|
|
| 9. |
XJDH-00425
|
[1] |
ELBOW-HOSE 90
|
|
| 10. |
XJDH-00427
|
[1] |
ELBOW-90
|
|
| 11. |
XJDH-01719
|
[1] |
MANIFOLD
|
|
| 12. |
XJDH-01376
|
[1] |
FILTER
|
|
| 13. |
XJDH-00394
|
[1] |
NIPPLE
|
|
| 14. |
XJDH-00415
|
[5] |
NIPPLE-HOSE
|
|
| 15. |
XJDH-00424
|
[1] |
ELBOW-HOSE 45
|
|
| 16. |
XJDH-00425
|
[1] |
ELBOW-HOSE 90
|
|
| 17. |
XJDH-00032
|
[2] |
BOLT
|
|
| 18. |
XJDH-00276
|
[2] |
WASHER
|
|
| 19. |
XJDH-02795
|
[1] |
VALVE-SOLENOID
|
|
| 20. |
XJDH-00467
|
[2] |
ELBOW-MALE 90
|
|
| 21. |
XJDH-00487
|
[1] |
CONNECTOR
|
|
| 22. |
XJDH-00328
|
[3] |
O-RING
|
|
| 23. |
XJDH-02824
|
[1] |
TEE
|
|
| 24. |
XJDH-02821
|
[1] |
ACCUMELATOR
|
|
| 25. |
XJDH-00406
|
[1] |
ELBOW-90
|
|
| 26. |
XJDH-00413
|
[1] |
VALVE-CHECK
|
|
| 27. |
XJDH-00415
|
[1] |
NIPPLE-HOSE
|
|
| 28. |
XJDH-00640
|
[1] |
HOSE(SP)
|
|
| 29. |
XJDH-00635
|
[1] |
HOSE(ST)
|
|
| 30. |
XJDH-00651
|
[1] |
HOSE(R5)
|
|
| 31. |
XJDH-00660
|
[1] |
HOSE(R3)
|
|
| 32. |
XJDH-00622
|
[1] |
HOSE(10)
|
|
| 33. |
XJDH-00658
|
[1] |
HOSE(Z)
|
|
| 34. |
XJDH-00665
|
[1] |
HOSE(T1)
|
|
| 35. |
XJDH-00781
|
[2] |
HOSE(PR,PL)
|
|
| 36. |
XJDH-00628
|
[1] |
HOSE(9)
|
|
| 37. |
XJDH-00503
|
[2] |
NIPPLE-HOSE
|
|
| 38. |
XJDH-01717
|
[1] |
BRACKET
|
|
| 39. |
XJDH-00035
|
[4] |
BOLT
|
|
| 40. |
XJDH-00276
|
[4] |
WASHER
|
|
| 41. |
XJDH-00140
|
[1] |
BOLT
|
|
| 42. |
XJDH-00278
|
[2] |
WASHER
|
|
| 43. |
XJDH-00180
|
[4] |
NUT
|
|
| 44. |
XJDH-00019
|
[4] |
BOLT
|
|
| 45. |
XJDH-00274
|
[4] |
WASHER
|
|
