纽荷兰零件查询(65B) - MOTORGRADERS (A2.33[001]) - ADVANCE VARIATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
303 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 769352 | [1] | DECAL KIT | MODVARIATOR, ADVANCE Superseded by part number: 4758943, 4758943, NLS |
| 1. | 767343 | [2] | ADVANCE DEVICE WEIGHT | HITFLYWEIGHT |
| 2. | 768185 | [2] | CUP | MKTPLATE Superseded by part number: 773140 |
| 3. | 767349 | [2] | SPRING | MKT Superseded by part number: 773242 |
| 4. | 767352 | [2] | SPRING | MKT Superseded by part number: 773280 |
| 5. | 766950 | [1] | HUB | PASHIM, 0.15MM(. 006"") Superseded by part number: 87029546 |
| . . | 766949 | [1] | WASHER | MKTSHIM,0.20MM(.008"") Superseded by part number: 773132 |
| . . | 766948 | [1] | HUB | PASHIM, 0.50MW. 020"") Superseded by part number: 858534 |
| 6. | 768213 | [2] | PISTON | NHPLATE Superseded by part number: 511953, 511297, 235759 |
| 7. | 758732 | [1] | LOCKING RING | BRERING Superseded by part number: 13421276, 13421276, 80758732 |
| 8. | 767346 | [1] | CONNECTING LINK | MKTLINK Superseded by part number: 773281 |
| 9. | 767347 | [2] | AXLE | PABLOCK, SLIDING |
| 10. | 768235 | [1] | SUPPORT | PABODY Superseded by part number: NLS, NLS, PA768235 |
| . . | 767342 | [2] | PIN | MKT |
| . . | 767350 | [2] | SCREW | LECCAPSCREW |
| . . | 11198071 | [2] | BELLEVILLE WASHER,Belleville, M8.4 | TORWASHER, SPRING, Belleville, M8.4 Superseded by part number: |
