现代零件查询R75-7 UPPER FRAME PIPING 6EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
344 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-00467
|
[12] |
ELBOW-MALE 90
|
|
| 2. |
XJDH-00328
|
[10] |
O-RING
|
|
| 3. |
XJDH-00470
|
[5] |
ELBOW-MALE 90
|
|
| 4. |
XJDH-00480
|
[1] |
ADAPTER-LONG 90
|
|
| 5. |
XJDH-00328
|
[17] |
O-RING
|
|
| 6. |
XJDH-00331
|
[5] |
O-RING
|
|
| 7. |
XJDH-00658
|
[1] |
HOSE(Z)
|
|
| 8. |
XJDH-00647
|
[1] |
HOSE(JJ)
|
|
| 9. |
XJDH-00650
|
[1] |
HOSE(KK)
|
|
| 10. |
XJDH-00657
|
[2] |
HOSE(LL,NN)
|
|
| 11. |
XJDH-00646
|
[1] |
HOSE(MM)
|
|
| 12. |
XJDH-00645
|
[1] |
HOSE(OO)
|
|
| 13. |
XJDH-00653
|
[2] |
HOSE(6,PP)
|
|
| 14. |
XJDH-00636
|
[1] |
HOSE(PA)
|
|
| 15. |
XJDH-00643
|
[1] |
HOSE(PB)
|
|
| 16. |
XJDH-00656
|
[1] |
HOSE(5)
|
|
