凯斯零件查询(438) - FLEX-AIR APPLICATOR - 1999 (2/99-3/03) (06-009) - BIN MOUNT GROUP, TRIPLE BIN, 50 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
292 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN306377
|
[6] |
HINGE
|
BN
CO-AP Bin
|
| 2. |
BN306380
|
[2] |
HINGE
|
BN
3/4" Rod, CO-AP
|
| 3. |
BN308071
|
[1] |
SUPPORT
|
TYR
Center, CO-AP Superseded by part number: 87529237, 87342769, 84188692, 84187133, 87343970
|
| 4. |
BN309338
|
[2] |
PIN
|
BN
5/8 With Shoulder
|
| 5. |
BN309339
|
[2] |
BAR
|
BN
Latch, Long
|
| 6. |
BN309340
|
[2] |
BAR
|
BN
Latch, Short
|
| 7. |
BN309409
|
[4] |
BUMPER
|
BN
2" DIA x 1-5/8" H, NPRN
|
| 8. |
BN309410
|
[4] |
BUMPER
|
BN
3/4-10, Thread Rod
|
| 9. |
BN309412
|
[8] |
WASHER,3/4, Stainless Steel
|
BN
|
| 10. |
BN309413
|
[4] |
SCREW,3/4" - 10, SST
|
BN
3/4-10, HJN, SS
|
| 11. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Group, Triple, RH, 50
|
| 13. |
BN310661
|
[2] |
CABLE
|
BN
CO-AP Bin
|
| 14. |
BN310662
|
[2] |
HOSE,6.00" ID x 6.00"
|
BN
COAP Bin
|
| 15. |
BN50146
|
[24] |
WASHER,3/8", Stainless
|
BN
|
| 16. |
BN50267
|
[4] |
BOLT,3/8"-16 x 2", Stainless Steel
|
BN
|
| 17. |
BN50593
|
[4] |
BOLT,1/2"-13 x 1-1/2", Stainless Steel
|
BN
|
| 18. |
BN50595
|
[8] |
WASHER,1/2", Stainless
|
BN
|
| 19. |
BN50600
|
[4] |
COTTER PIN
|
BN
3/16" X 1&1/2" Superseded by part number: 80754
|
| 20. |
BN50661
|
[8] |
NUT,3/4"-10, Stainless Steel
|
BN
|
| 21. |
BN50679
|
[4] |
BOLT,1/2-13 X 1.25", Stainless
|
BN
|
| 22. |
BN50759
|
[16] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 23. |
BN55363
|
[8] |
LOCK NUT,1/2"-13, Nylon, Stainless
|
BN
|
| 24. |
BN55365
|
[2] |
LOCK NUT,5/8"-11, Nylon, Stainless
|
BN
|
| 25. |
BN55373
|
[12] |
BOLT,3/8"-16 X 3-1/2", Stainless Steel
|
BN
|
| 26. |
BN71007
|
[4] |
CLIP,3/16" Hairpin
|
BN
Hairpin-3/16" #8
|
| 27. |
BN85064
|
[4] |
HOSE CLAMP
|
BN
6" Bridge Superseded by part number: 84541279
|
