纽荷兰零件查询(65B) - MOTORGRADERS (A2.35/2[001]) - NOZZLE HOLDER (CAV) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
701 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 770899 | [6] | INJECTOR NOZZLE HOLDER | MODHOLDER. NOZZLE Superseded by part number: 4760842 |
| 1. | 9928367 | [1] | BANJO BOLT | MODUNION |
| 2. | 2852057 | [2] | SEALING WASHER,M8 x 12 x 1 Thk | TORGASKET |
| 3. | 9928374 | [1] | RING NUT | MODRING |
| 4. | 9928366 | [1] | GASKET | MODGASKET |
| 5. | 9928371 | [1] | RING NUT | MODPLUG |
| 6. | 9928369 | [1] | SPACER | MOD |
| 7. | 9928370 | [1] | SPRING | MOD |
| 8. | 9928375 | [1] | ROD | MOD |
| 9. | 9928376 | [2] | DOWEL | MOD |
| 10. | 9928373 | [1] | RING NUT | MODRING |
