神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (17-074) - LINER & PISTON KIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
436 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-6. | VAME999993 | [3] | LINER, ENGINE CYLIND | KOBSLEEVE & PISTON, 2 CYL 6D31T M5 ONLY Superseded by part number: VAME997440 |
| . . | VAME997440 | [3] | LINER, ENGINE CYLIND | KOBSLEEVE & PISTON, 2 CYL 6D31T M6 ONLY, Start Serial: 9004- |
| . . | VAME999993 | [3] | LINER, ENGINE CYLIND | KOBSLEEVE & PISTON, 2 CYL 6D31T M6 ONLY, Serial Range: --9003 Superseded by part number: VAME997440 |
| 1. | VAME011626 | [6] | SLEEVE CYLINDER | KOB |
| 2. | VAME012858 | [6] | PISTON | KOBSTD M5 ONLY |
| . . | VAME012858 | [6] | PISTON | KOBSTD M6 ONLY |
| 3. | VAME999842 | [6] | PISTON RING SET, 1CYL M5 ONLY | |
| . . | VAME997442 | [6] | PISTON RING SET, 1 CYL M6 ONLY, Start Serial: 9004- | |
| . . | VAME999842 | [6] | PISTON RING SET, 1 CYL M6 ONLY, Serial Range: --9003 | |
| 4. | VAME012009 | [6] | PISTON PIN | KOB |
| 5. | VAME012061 | [12] | SNAP RING | KOB Superseded by part number: VAME015917 |
| 6. | VAME012234 | [6] | BUSHING | KOB |
